Hardware Installation
2.5.2 Serial Port
COM
The system board is equipped with an onboard serial port (Teal/
Turquoise) at location CN4 of the system board. It is a RS-232C
asynchronous communication por t with 16C550A-compatible
UART that can be used with a modem, serial printer, remote
display terminal or other serial devices.
BIOS Setting
Select the serial port's I/O address in the Integrated Peripherals
submenu ("Super IO Device" section) of the BIOS. Refer to
chapter 3 for more information.
