Chapter 1 - Introduction

1.1 Features and Specifications

1.1.1 Features
Chipset
• Intel 865PE chipset
®
®
- Intel
®
- Intel
Processor
The system board is equipped with Socket 478 for installing one
of the following supported processors.
®
• Intel Pentium
- 800MHz/533MHz system data bus
®
• Intel Pentium
- 533MHz/400MHz system data bus
®
• Intel Celeron
- 400MHz system data bus
System Memory
• Supports four 184-pin DDR DIMM sockets
• Supports dual channel (128-bit wide) memory interface
- Each channel supports 2 DIMM sockets
• Supports up to 4GB system memory
• Synchronous operation with processor system bus
- PC2100/PC2700/PC3200 (DDR266/DDR333/DDR400)
with 800MHz FSB CPU. DDR333 will run at 320MHz
memory frequency when used with 800MHz FSB CPU.
- Use PC2100/PC2700 (DDR266/DDR333) with 533MHz
FSB CPU
- Use PC2100 (DDR266) with 400MHz FSB CPU
• Suppor ts non-ECC (x64) DIMM using 128Mb, 256Mb or
512Mb
• Supports unbuffered DIMMs
865PE Memory Controller Hub (MCH)
82801EB I/O Controller Hub (ICH5)
®
4 Processor with Hyper-Threading Technology
®
4 Northwood processor
®
Northwood processor
