Cable Type - Altronix Pace1PTM Installation Manual

Fig. 3
OUT
Ports
1 4 5
IN
Powered Switch or NetWay MidSpan
Maximum Length of Cable Type vs. Camera Power/PoE Class:

Cable Type

Cat5e
Cat5e
1 Pair UTP
1 Pair UTP
Note: Calculations based on 56VDC starting voltage from power source and accounts for a
10VDC voltage drop. IEEE standards voltage range requirement for powered devices are:
PoE (15W) - 37VDC to 57VDC
PoE+ (30W) - 44VDC to 57VDC.
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A.
IIPace1PTM
- 4 -
Multiple PoE Cameras Connection:
Pace8PRM shown. Pace4PRM and Pace16PRM are similar,
with four (4) and sixteen (16) channels respectively.
OUT
Ports
8
IN
Total Power
Consumption
15W
30W
15W
30W
450m max.
450m max.
450m max.
450m max.
450m max.
450m max.
450m max.
450m max.
Pace8PRM
- Front Panel
Data Distance
G22O
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Pace1PTM
Max.
500m
500m
150m
150m
PoE compliant
100m max.
PoE Camera
PoE compliant
100m max.
PoE Camera
PoE compliant
100m) max.
PoE Camera
PoE compliant
100m max.
PoE Camera
PoE compliant
100m max.
PoE Camera
PoE compliant
100m max.
PoE Camera
PoE compliant
100m) max.
PoE Camera
PoE compliant
100m max.
PoE Camera
Max.
Power Distance
846m
423m
210m
105m
MEMBER
Pace1PTM
