Altronix Pace1PTM Installation Manual page 3

Fig. 1
Fig. 1a
P5 P6
UTP
Link
Top View
Green LED
indicates
PoE Present
Endspan
Structured
Cable to
Midspan/
Endspan
Fig. 2
Pace1PRM
Pace1PRM - Receiver
IP-UTP Receiver
Passes PoE/PoE+
RJ45 LEDs Yellow - Activity
Green - Speed
Green LED Power and PoE
Z1409
I.T.E. 43KC
Output
UTP RJ45 PoE
Link Link LED
100m max.
Powered Switch or MidSpan
Pace1PTM
Fig. 1b
Single UTP
from
Pace1PRM
CAT5 or higher
from Pace
receiver
Single PoE Camera Connection:
www.altronix.com
Input
PoE PoE
Input LED
PoE+ over CAT5e up to 500m max.
Single UTP up to 152.4m max.
Jumper
P6
P5
Side View
Green LED
indicates
PoE received
from Pace1PRM
or
To access pins which are located
behind the UTP Link you must
remove cover.
Note: Make sure jumpers are lined
up with pins pairs [P5] and [P6] as
shown in top and side views noted
in Figs. 1a & 1b.
Green LED
indicates
PoE transmitted
to Camera/Device
Structured
Cable from
Camera/Device
Mounting Hole
Pace1PTM
Pace1PTM - Transceiver
IP-UTP Transceiver
Passes PoE/PoE+
RJ45 LEDs Yellow - Activity
Green - Speed
Green LED Power and PoE
www.altronix.com
Z1409
I.T.E. 43KC
Input Output
UTP RJ45 PoE
PoE PoE
Link Link LED Out LED
PoE compliant
100m max.
Fig. 2a
PoE Camera
Legend:
Structured Cable
or Single UTP
- 3 -
