Horizontal Ducting Conversion - Zephyr Cypress AK7836BS Use, Care And Installation Manual

This range hood is equipped standard with a 10" round vertical duct option. To convert from 10" round vertical to
10" round horizontal ducting please following the instructions below.
VERTICAL TO HORIZONTAL DUCTING CONVERSION
1. Disconnect blower plug.
3. Knock out plate A for dual blower horizontal
ducting.
5. Position dual blower plate onto interior back wall
mounting brackets inside hood body. Attach by
connect blower plug.
attaching blower plate to top of hood body.
Remove blower and blower plate.
A
4. From inside hood body, position top cover plate
to top of hood body. From outside hood body,
attach top cover plate to top of hood body using
6. Attach 10 inch round blower collar to back of
