2. CABLE CONNECTION AND WIRING
2.3

Data Signals

Position
Course true
Course magnetic
Speed over the ground
Water speed and heading
Distance to waypoint
Destination waypoint, true
Destination waypoint, magnetic
Heading (true)
Heading (magnetic)
Magnetic variation
Cross-track error
Depth
Temperature
Wind (true)
Wind (relative)
Time
2.4

Input/Output Ports

2.4.1 HDG port
This port is for AD-10 format.
Parameter Rating
Forward 50mA
Current
Reverse 6V
Voltage
Forward 1.1V (TYP)
Voltage 1.4V (MAX)
Parameter Rating
Forward 50mA
Current
Reverse 6V
Voltage
Forward 1.1V (TYP)
Voltage 1.4V (MAX)
GNS>GGA>RMC> GLL
VTG>RMC
VTG>RMC (true)
VTG>RMC
VHW
BWR>BWC>RMB
BWR>BWC>RMB
BWR>BWC
THS>HDT>VHW (true)>HDG>HDM>VHW (magnetic)
HDG> HDM>VHW (magnetic)THS>HDT>VHW (true)
HDG>RMC
XTE>RMB
DPT>DBT
MTW
MWV>VWT
MWV>VWR
ZDA
Remarks
Absolute
Maximum
GYRO_DATA_H
Absolute
Maximum
I =4mA
F
GYRO_DATA_C
Remarks
Absolute
Maximum
GYRO_CLK_H
Absolute
Maximum
I =4mA
F
GYRO_CLK_C
23
Circuit Diagram
490Ω
Photocoupler
Circuit Diagram
490Ω
Photocoupler
