1.
HOW TO INSTALL THE SYSTEM
1.1
Display Unit
Select a location for the display unit by following the information shown below.
• The unit is waterproof, but FURUNO recommends that you install the display unit in
a cabinet.
• Keep the unit away from direct sunlight.
• The temperature and humidity must meet the requirements shown in the equipment
specifications.
• Set the unit away from the exhaust pipes and vents.
• The installation location must have enough cool air.
• Install the unit where shock and vibration meet the requirements shown in the
equipment specifications. If there is heavy vibration, vertically install the display unit
on the hanger.
• Keep the unit away from equipment that creates an electromagnetic field, for exam-
ple, motors and generators.
• For maintenance and checking, leave enough space at the sides and rear of the
unit, referring to the outline drawing and provide some additional length in cables.
• Follow the recommended compass safe distances shown on page i to prevent the
interference to a magnetic compass.
NOTICE
Do not apply paint, anti-corrosive sealant or
contact spray to plastic parts or equipment
coating.
These items contain products that can
damage plastic parts and equipment coating.
1
