Multi Variable Air Conditioners
Cassette Type Indoor Unit Owner's Manual
This instruction is suitable for the following model:
TGS-28FWCA
TGS-36FWCA
TGS-45FWCA
TGS-50FWCA
TGS-56FWCA
TGS-63FWCA
TGS-71FWCA
TGS-80FWCA
TGS-90FWCA
TGS-100FWCA
TGS-112FWCA
TGS-125FWCA
TGS-140FWCA

Advertisement

Table of Contents
loading

Summary of Contents for Toyotomi TGS-28FWCA

  • Page 1 Multi Variable Air Conditioners Cassette Type Indoor Unit Owner’s Manual This instruction is suitable for the following model: TGS-28FWCA TGS-36FWCA TGS-45FWCA TGS-50FWCA TGS-56FWCA TGS-63FWCA TGS-71FWCA TGS-80FWCA TGS-90FWCA TGS-100FWCA TGS-112FWCA TGS-125FWCA TGS-140FWCA...
  • Page 3: Table Of Contents

    Please read this instruction carefully before operating Thank you for your selecting of TOYOTOMI air conditioner, please read this usage and install instruction carefully and keep it well in order to use this unit correctly. USER NOTICES Safety information Install the cassette type indoor unit...
  • Page 5: User Notices

    USER NOTICES ☆ When operating, the entire capacity of the cooperating indoor unit should be not larger than that of outdoor unit. Otherwise, it will cause the shortage of cooling (heating) capacity. ☆ A Breaker(or fuse) need to be installed in every indoor unit, and the capacity should in according with indoor unit’s electrical parameter;...
  • Page 6 ☆ Missing information regarding installation altitude (max 1000m) in documentation ☆ Information regarding transport/storage temperature (-25-55°C) is missing ☆ Main switch provided by end user: main switch handle should be black or gray, it can be locked in “OFF” position with padlock ☆...
  • Page 7: Safety Information

    Safety information Please read this manual carefully before use this unit, and operate it correctly according to the guide in this manual. 1. Please take specially note to the meaning of these two marks: Warning! : This mark means that it may cause casualty or badly heart if the operation is incorrect. Note!...
  • Page 8: Install The Cassette Type Indoor Unit

    ≥ 1 5 0 0 M o d e l G M V (L )-R 2 8 T /N a -K TGS-28FWCA TGS-36FWCA ≥ 1 5 0 0 2 1 0 G M V (L )-R 3 6 T /N a -K...
  • Page 9: Install The Cassette Type Indoor Unit

    ☆ Please contact the local TOYOTOMI special nominated repair department before installation. Any malfunction caused by the unit that is installed by the department that is not special nominated by TOYOTOMI would not deal with on time by the inconvenience of the business contact.
  • Page 10 Install of the Cassette type indoor unit ● Main body of hoisting air conditioner 1 The primary step for install the indoor unit. ☆ When attach the hoisting stand on hoisting screw, do use nut and gasket individually at the upper and lower of the hoisting stand to fix it.
  • Page 11 Install of the Cassette type indoor unit ● Connect the refrigerant pipe ☆ When connect the pipe to the unit or backout it from the unit, please do use both spanner and torque wrench. as shown in fig.3. ☆ When connect, smear both inside and outside of the flare nut with freeze motor oil, screw it by hand and then tighten it with spanner.
  • Page 12 Install the cassette type indoor unit 1-1.5m ○ × (Correct) 1/100 or more gradient (wrong) ☆ Use the drain hose and clamp attached. Insert the drain Sponge(attachment) hose to the drain vent, and then tighten the clamp. Clamp Clamp(attachment) ☆ Entwine the big sponge on the clamp of drain hose to insulate heat.
  • Page 13 Install the cassette type indoor unit 2 Check the smoothness of drain after installation. ☆ Check the drain state by immitting 600cc water slowly from the outlet vent or test hole. ☆ Check the drain in the state of refrigerating after installation of the electric circuit. [ Way of immiting ] Drain hose Test hole cover...
  • Page 14: Electrical Wiring

    Install the cassette type indoor unit ● Electrical wiring Note: The power of the entire indoor unit must be unity power supply ☆ About the electrical wiring, please see the circuit diagram attached with the unit. ☆ All the installation of electrical wiring must be done by professional personnel. ☆...
  • Page 15 Install the cassette type indoor unit Function description of functional dial switch S7 ● 1. The 3-bit dial switch must be set before energizing the main board and it determines running state of indoor unit. 2. Function of it is as follow: Dial switch Function Dial ON...
  • Page 16 Install the cassette type indoor unit ● Install the panel 1. Set the panel to the indoor unit body by matching the position of the swing flap motor of the panel to the piping position of the panel to the piping position of the indoor unit as shown by fig.4. 2.
  • Page 17 Install the cassette type indoor unit Note 1. Improper screwing of the screws may cause the troubles shown in fig.5. Air leak Air leak from ceiling Water condensatation, water drop Fig.5 2. If gap still exist between ceiling and decoration panel after tightening the screws, readjust the height of the indoor unit. (As shown in fig.6) If the raising lever and drain hose are not affect, can adjust the height of...
  • Page 18: Constitutes And Names Of Parts Of Cassette Type Indoor Unit

    Discharge condensate water from indoor unit when cooling Drainage hose Guide louver (placed in air outlet vent) Air outlet vent Connecting pipe Air filter, purifier (in air inlet grille) Air inlet grille TGS-28FWCA TGS-36FWCA TGS-45FWCA TGS-50FWCA TGS-56FWCA TGS-63FWCA TGS-71FWCA TGS-80FWCA TGS-90FWCA TGS-100FWCA TGS-112FWCA...
  • Page 19: The Components Of The Wired Remote Control

    Wired Remote Controller Operation Procedure The components of the wired remote control MODE SWING TIMER ON/OFF Fig.1 Every part of wired remote controller Operating mode display (Cool, Dry, Fan, On/Off button Heat) Sleep mode display Timer button Environmental temp. display Swing button Malfunction display Fan control display (automatic, high,...
  • Page 20: Timer Setting

    Wired Remote Controller Operation Procedure (Fig.3, the following sketch is displayed according 2) Timer setting to the functions of wired remote controller) Press TIMER under off state can set On Time; press TIMER MODE under on state can set Off Time. Under the circumstance that without setting time ( there isn’t information in the Timer Time Display Zone), press TIMER, then the LCD will display the pattern of “...
  • Page 21: Sleep Mode Setting

    Wired Remote Controller Operation Procedure (fig.4) 3)SLEEP mode setting When under the cooling or dehumidifying mode, after MODE receiving the SLEEP order for 1 hour, the previous set temp. will be risen for 1℃, and another 1℃ will be risen after 2 hours that means that the temperature been risen 2℃...
  • Page 22: Temp. Adjusting

    Wired Remote Controller Operation Procedure (Fig.7) 6)Temp. adjusting Under the state without time setting, press“▲”and“▼”to adjust temp.. ▲:To rise set temp.; MODE ▼:To reduce set temp. ( every press of this button, temp. will be risen or subtracted for 1℃.) Temp.
  • Page 23 Wired Remote Controller Operation Procedure When controller displaying malfunction, please turn off the unit to stop displaying and has it repaired by specialized personnel. The meaning of malfunction code is as following: Malfunction code Malfunction High pressure protection of compressor Indoor anti-frozen protection Low pressure protection of compressor Discharge temp.
  • Page 24: Names And Functions Of Every Button Of The Remote Control

    Remote controller operation procedure Names and functions of every button of the remote control The remote control of the Ducked type indoor unit is shop piece. NOTE! ● Make sure that there is no obstruction between the remote control and the signal receptor. ●...
  • Page 25: Names And Functions Of Every Button Of The Remote Control (Remove The Cover)

    Remote controller operation procedure Names and functions of every button of the remote control (Remove the cover) NOTE! This type of remote control is a kind of general use remote control that is suitable for several types (function) of air conditioner units. Please understand that the functions and buttons that are not suitable for this air conditioner will not be introduced.
  • Page 26: Operation Procedure

    Remote controller operation procedure Operation procedure Normal procedure 1. Press ON/OFF button after connected with the power, then the unit is operating. 2. Press MODE button to choose the need operation mode. 3. Press button SWING to make the guide louver swings according to certain angle when press once; repress once to stop operating.
  • Page 27: Operation Method When Meeting An Emergency

    Operation Method When Meeting An Emergency ● Operation Method When Meeting An Emergency When wireless remote controller is lost or damaged, the following method could be adopted to control cassette type indoor unit: ☆ When the unit is turned off, press AUTO button on corner outer coverⅡ, then the unit begin operate in cooling with the fan run in high speed.
  • Page 28: Malfunction Debarring

    Malfunction Debarring Warning! Cut down the main power switch immediately if malfunction (such as smell the burning odor etc.) happened, and service center then contact . If the abnormal state is maintained, the unit may be damaged or electric shock or fire may be happened.
  • Page 29 Malfunction Debarring ● The following circumstance are not malfunction “Malfunction” Reason The overload protects switch makes it run Start up unit immediately after turned off Air conditioner doesn’t after 3 minutes delay. Run for about 1 minute without other When opening power actions Mist is blown from air The high humidity air in room is cooled...
  • Page 30: Maintenance Method

    Maintenance Method When air conditioner won’t be used for a long time, please cut off the main power supply of air conditioner. Warning! Do turn off the unit and cut off the main power supply when cleaning the air conditioner, otherwise electric shock or harm may happen.
  • Page 31 Maintenance Method Fig. III Fig. IV ● Clean air inlet grille 1. Open air inlet grille (the same with the 1st step of Clean Air Filter) 2. Take out air filter (the same with the 2nd step of Clean Air Filter) 3.
  • Page 32 ☆ Could adsorb deleterious material that is smaller than 1μm in air, as dust, pollen, bacteria, and virus. ☆ Usage period is 6 months to 1 year. If it is necessary to be changed, purchase new purifier in the nearest TOYOTOMI special engaged maintenance center. ● Clean Outlet vent and Surface Panel ☆...
  • Page 33: Model And Technical Parameter

    Model and Technical Parameter ● Parameter of cassette type indoor unit Model TGS-28FWCA TGS-36FWCA TGS-45FWCA TGS-50FWCA Function Cooling and heating Cooling and heating Cooling and heating Cooling and heating Cooling Capacity (kW) Heating Capacity (kW) Air Flow Rate(m /h) Sound Level (dB (A) )...
  • Page 34 Function Cooling and heating Cooling and heating Cooling and heating Cooling and heating Cooling Capacity 10.0 11.2 12.5 (kW) Heating Capacity 10.0 11.0 12.5 13.5 (kW) Air Flow Rate(m /h) 1860 1860 1860 1860 Sound Level ( dB (A) ) 0.06 0.06 0.06...
