- Page 1 Installation and Operation Manual Multi VRF Floor Standing Indoor Unit Applicable models： TGS-71FSA-E TGS-100FSA-E TGS-140FSA-E Please read this manual carefully before using this product and keep it properly for future reference!
-
Page 3: Table Of Contents
CONTENTS Ⅰ USER NOTICES ....................1 Ⅱ SAFETY INFORMATION ................2 Ⅲ INSTALLATION INSTRUCTIONS ............... 3 3.1 Installation Precautions..................... 3 3.2 Schematic Diagram of Installation Space ..............4 3.3 Piping ........................4 3.4 Installation of the Baffle ................... 5 3.5 Electrical Connection ....................5 Ⅳ... -
Page 5: Ⅰ User Notices
Ⅰ USER NOTICES Thank you for your selection of TOYOTOMI air conditioners. Before installation and operation, please read this manual carefully and keep it in handy place for future reference. During the operation, the entire capacity of the cooperating indoor unit should be not larger than that of outdoor unit. -
Page 6: Ⅱ Safety Information
Ⅱ SAFETY INFORMATION Please read this manual carefully before use this unit, and operate it correctly according to the guide in this manual. Also, please take specially notices to the meaning of these two symbols： Warning！This mark means that it may cause casualty or badly hurt if the operation is incorrect. Note！This mark means that it may cause casualty or property loss if the operation is incorrect. -
Page 7: Ⅲ Installation Instructions
Ⅲ INSTALLATION INSTRUCTIONS 3.1 Installation Precautions Notes for Installation The unit installation work must be done by qualified personnel according to the local rules and this manual When removing the unit to the other place, please firstly contact with the local maintenance center. 3.1.1 Basic Requirements for Installation Location Installation at the following places may cause failure of the air conditioner. -
Page 8: Schematic Diagram Of Installation Space
Any malfunction caused by the unit that is installed by the department that is not special nominated by TOYOTOMI would not deal with on time by the inconvenience of the business contact. It should be guide under the professional personnel when the air conditioner unit is moved to other place. -
Page 9: Installation Of The Baffle
At last take out the filter along the arrow direction at position 3. During piping and wiring in the left and at the rear side, the attached accessories should be used, as shown in Fig.4。 Models Gas Pipe（mm/inch） Liquid pipe（mm/inch） TGS-71FSA-E Φ16 Φ9 TGS-100FSA-E Φ16 Φ9 TGS-140FSA-E Φ16... - Page 10 The min. clearance between combustible surface and the air conditioner is 1.5 meters. g. The indoor unit and outdoor unit must be reliably earthed. Air switch capacity Min. sectional area of power cord （ mm ） × core Models Power Supply TGS-71FSA-E (H05VV-F) 1.0 mm ×3 TGS-100FSA-E 220-240V/50Hz (H05VV-F) 1.0 mm ×3 TGS-140FSA-E (H05VV-F) 1.0 mm...
-
Page 11: Ⅳ Working Temperature Range
3.5.4 Other The auxiliary electric heater is assembled near the back of evaporator in the indoor unit and it is a tubular metal electric heating element. As for the power supply, please refer to the nameplate on the unit body. 3.5.5 Electrical Wiring Open the glass panel. -
Page 12: Ⅴ Control
Ⅴ CONTROL 5.1 Control Panel Note： About functions “AUTO”, “AIR”, “ROOM’, “OFFICE”, “RESTAURANT”, and “COMMON”, they are currently unavailable for this unit but reserved. 5.1.1 Keys on the Control Panel Keys on the face panel: ON/OFF, Mode, Light, ▲, ▼, Function, Speed ON/OFF Press this key to switch on/off the unit. - Page 13 by pressing this key. After some function is selected, if there is no “Turn-off” operation or there is no remote control ③ signal within two minutes, then press this key again to go to the circular functions selection starting from the set function. Two minutes later or if there is “Turn-off” operation or there is a remote control signal, then press this key again to go to the circular functions selection starting from the first function.
- Page 14 Then, another press on these two keys will unlock the keypad. Memory Under the “Off” status of the unit, it is available to switch the memory mode by pressing the keys “Mode” and “▲” simultaneously. When “88” LED displays “ON”, it indicates the memory function is activated; if “OF” is displayed, it indicates that the memory function is deactivated.
-
Page 15: Wireless Remote Controller
5.2 Wireless Remote Controller Table 2: Functions of Each Keys of the Wireless Remote Controller Name Function Press this button, the unit will be started or stopped, which can clear ON/OFF button the timer or sleeping function of last time. When press + button , the setting temp. - Page 16 In Stationary swing mode, press this button ,the angle for Up and down swing as show in below: When up and down swing louver is working, when turn off the unit, the siwng louver will immediately stop at current position. shows up and down swing louver swings back and forth as show in the above figure.
- Page 17 under auto, dehumidify or fan mode, and characters of turbo won’t appear. Press this button, enter into SLEEP state, when repressed, it will quit. The sleep function will be canceled with the stop of the unit. There is no SLEEP function under AUTO and FAN mode. is the icon for sleep function.
-
Page 18: Guides For General Operation
5.3 Guides for General Operation ① Press ON/OFF button to start the unit after powering the main unit on.(Note: Power the unit on every time, the big -guide louver and small-guide louver will be closed firstly.) ② Press MODE button to select desired running mode. ③... -
Page 19: Replacement Of Batteries
Under the COOL or DRY mode, by pressing the key “Function”, it is available to active the blow function with the indicating lamp flashing and then through the key ▲ /▼ to select the desired options, “Blow on” or “Blow off”. Under the COOL or DRY mode (Blow function is unavailable under the COOL and FAN modes), if the blow function is activated, the fan of the indoor unit will still run for another ten minutes at the low speed after the indoor unit is turned off. -
Page 20: Adjustment Of Swing Directions
Notes: ① When changing the batteries, do not use the old or different batteries, otherwise, it can cause the malfunction of the wireless remote control. ② If the wireless remote control will not be used for a long time, please take them out, and don't let the leakage liquid damage the wireless remote control. -
Page 21: Ⅵ Care And Maintenance
5.6.2 Left & Right Swing Left & right swing can be selected to control start or stop of left & right swing motor by pressing left & right button on remote controller or FUNC button on displayer, so that guide louver will swing left and right or stop at a certain angle. -
Page 22: Cleaning The Air Filter
Cut power off before cleaning and turn off the air switch after unit stops running. Use soft cloth when cleaning cabinet. If the unit is very dirty, dip cloth into warm water below 40℃ and dry the cloth before cleaning it. Don’t spray water on indoor unit, as spraying water will damage microcomputer and circuit board in the unit. - Page 24 66129909116...
