MODEL: CSH-ExxSX
1 - Hood Body
2 - Baffle Filters (1 - 36" model)
4 - GU-10, 120V, 50W Halogen Bulbs
1 - Hood Door
2 - Telescopic Duct Covers
1 - Ceiling Mounting Bracket
1 - HARDWARE PACKET
7 - 2" wood screws
7 - anchors
7 - 1/2" washers
4 - screws (Dimension 5 x 15mm)
4 - adhesive fastener (to hold cable tie)
4 - cable tie
1 - HARDWARE PACKET, EXTERNAL BLOWER KIT
1 - 8" collar
1 - external blower connection box
10 - 1/2" self tapping screws
6 - 4mm internal diameter washer
1 - wiring for the connection to external blower
NO DUCTING IS PROVIDED
EXTERNAL AND INTERNAL BLOWER SOLD SEPARATELY
Make sure to remove the protective film off of the hood before installation in order to make removal of the film
easie r. Be careful not to scrat ch the stainless steel while installing.
3
