2700 I-ACC
B. Clearances to Combustibles,
WARNING
Fire Risk.
•
Comply with all minimum clearances to
combustibles as specifi ed.
•
Failure to comply may cause house fi re.
In Canada a full length 6 inch (152mm) S635 fl ue liner required as per ULC S628.
In USA a minimum 5 ft length (1.82m), 6 inch (152mm) diameter fl ue liner is required as per UL 1482.
8
United States and Canada (UL and ULC)
TOP TRIM
28 1/2
724mm
USA 16-3/4
CANADA
20-3/4 (527mm)
CANADA 19 (483mm)
43-1/2
1105mm
HEARTH EXTENSION
See next page for thermal protection
requirements
7046-192C
21-3/4
552mm
HEARTH
EXTENSION
12in max
MANTEL
USA 17
NOTE: Clearances may only be reduced by means
approved by the regulatory authority having juris-
diction
36-1/16
916mm
May 14, 2015
