Table Of Contents - Quadra-Fire 27I-ACC Installation Manual

2700 I-ACC
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
Important Safety Information
1
A. Insert Certifi cation .............................................................3
B. BTU & Effi ciency Specifi cations........................................3
C. Mobile Home Approved .................................................... 3
D. Glass Specifi cations .........................................................3
E. Non-Combustible Materials ...............................................3
F. Combustible Materials ........................................................3
Getting Started
2
A. Design and Installation Considerations ..................................4
B. Draft...... .............................................................................4
C. Negative Pressure ............................................................5
D. Tools And Supplies Needed ..............................................5
E. Inspect Appliance and Components ..................................5
F. Install Checklist .................................................................6
Dimensions and Clearances
3
A. Appliance Dimensions ......................................................7
B. Clearances to Combustibles, ............................................8
C. Calculating Alternate Floor Protection ..............................10
D. Locating Your Stove & Chimney .......................................11
E. Chimney Termination Requirements .................................11
F. 2-10-3 Rule .......................................................................12
2

TABLE OF CONTENTS

Chimney Systems
4
A. Venting Systems ...............................................................13
B. Inspections........................................................................13
C. Larger Chimneys ..............................................................13
D. Masonry Chimney.............................................................13
E. Metal Heat Circulating Masonry .......................................15
F. Prefabricated Metal Chimney ............................................15
G. Securing Chimney Components.......................................16
H. Altering the Fireplace ........................................................16
I. Zero-Clearance Fireplace ..................................................17
J. Ovalizing Round Stainless Steel Liners ............................17
K. Chimney Height / Rise and Run .......................................17
Appliance Set-Up
5
A. Outside Air Kit Installation ..................................................18
B. Securing Stove Pipe/Liner to Flue Collar ..........................19
C. Leveling Legs ..................................................................19
D. Securing Appliance to Stove Pipe/Liner ...........................20
E. Surround & Trim Kit Installation ........................................20
F. Blower Cord Installation on Left Side .................................22
G. Zero Clearance Adjustable Trim Support, 2" to 10" .........23
Mobile Home Installation
6
Accessory List
7
A. Accessory List ....................................................................25
B. Installation Notes ...............................................................26
7046-192C May 14, 2015
