Quadra-Fire 21M-ACC Owner's Manual

Quadra-Fire 21M-ACC Owner's Manual

2100 millennium wood appliance automatic combustion control (acc)
Hide thumbs Also See for 21M-ACC:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Operation & Installation Manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with question on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
2100 MILLENNIUM WOOD APPLIANCE
AUTOMATIC COMBUSTION CONTROL
MODEL:
21M-ACC
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
(ACC)
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
•
Do not over-fire - If appliance or chimney connector
glows, you are over-firing. Over-firing will void your
warranty.
•
Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
Hot glass and appliance will cause burns.
•
Do not touch glass until it is cooled
•
Use leather gloves when reloading fuel
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
appliance.
•
Alert children and adults to hazards of high
temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
Fire Risk.
For use with solid wood fuel only.
Other fuels may over-fire and generate
poisonous gases (i.e. carbon monoxide).
To obtain a French translation of this manual, please
contact your dealer or visit
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez
www.quadrafire.com
7039-177C
WARNING
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
WARNING
NOTE
www.quadrafire.com
August 13, 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 21M-ACC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quadra-Fire 21M-ACC

Summary of Contents for Quadra-Fire 21M-ACC

  • Page 1 • Comply with all minimum clearances to combustibles MODEL: as specified. Failure to comply may cause house fire. 21M-ACC WARNING HOT SURFACES! Glass and other surfaces are hot during operation AND cool down. Hot glass and appliance will cause burns.

  • Page 2: Sample Of Serial Number / Safety Label

    2100 Millennium NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label ITEM PART NUMBER PART NAME LOCATION: Back of appliance CAUTION HOT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN AND CLOTHING AWAY. CONTACT MAY CAUSE SKIN BURNS. KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL FAR AWAY FROM THE APPLIANCE.

  • Page 3: Table Of Contents

    L. Negative Pressure ......16 M. Frequently Asked Questions....17 Quadra-Fire is a registered trademark of Hearth & Home Technologies. August 13, 2018...

  • Page 4: Warranty Policy

    2100 Millennium B. Warranty Policy Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: WARRANTY PERIOD: distributor, whichever occurs earlier.
  • Page 5 2100 Millennium WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. •...
  • Page 6 2100 Millennium This warranty is void if: • • • There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited LIMITATIONS OF LIABILITY • have other rights, which vary from state to state. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN.

  • Page 7: Quick Start Guide

    2100 Millennium C. Quick Start Guide Note: These are generic drawings and may not represent your specific model. 10 Pieces of Newspaper, 10-20 Pieces of Dry Kindling ITEMS NEEDED FOR FIRST FIRE: and a Few Pieces of Dry Split Wood. OPEN AIR LOAD WOOD ADD NEWSPAPER...

  • Page 8: Listing And Code Approvals

    NOTE: This installation must conform with local codes. In the absence of local codes you must comply with (UM) 84- HUD and NFPA211 in the U.S.A. and CAN/CSA-B365 Installation Codes in Canada. The Quadra-Fire 2100 Millennium Wood Appliance (ACC) meets the U.S. Environmental Protection Agency’s crib wood emission limits for wood appliances sold after May 15, 2015.

  • Page 9: Glass Specifications

    2100 Millennium C. Glass Specifications WARNING This appliance is equipped with 5mm ceramic glass. Replace glass only with 5mm ceramic glass. Please Fire Risk. contact your dealer for replacement glass. Hearth & Home Technologies disclaims any D. Mobile Home Approved responsibility for, and the warranty will be voided •...

  • Page 10: Operating Instructions

    Chimney connector or appliance glowing placed on the burning of wood for home heating. In order • Roaring, rumbling noises to improve the situation, we at Quadra-Fire have developed • Loud cracking or banging sounds cleaner-burning wood appliances that surpass the •...

  • Page 11: Air Controls

    2100 Millennium E. Using Burn Rate Air Control & ACC System 2. Second Stage The next stage of burning, the secondary stage, is the 1. Start up and Reloading Fuel period when the wood gives off flammable gases which Open both Burn Rate Air Control and ACC systems fully. To burn above the fuel with bright flames.

  • Page 12: Burn Rates And Operating Efficiency

    2100 Millennium F. Burn Rates and Operating Efficiency WARNING For maximum operating efficiency This wood appliance has a manufacturer-set minimum Risk of Fire. low burn rate that must not be altered. It is against federal When set on High Burn Rate and over-riding the regulations to alter this setting or otherwise operate this Automatic Combustion Control system an over fire wood appliance in a manner inconsistent with operating...

  • Page 13: Building A Fire

    2100 Millennium G. Building A Fire NOTE: Before lighting your first fire in the appliance: • Build fire on brick firebox floor. NOTE: The special high temperature paint that your • Do NOT use grates, andirons or other methods to appliance is finished with will cure as your support fuel.

  • Page 14: Correct Baffle & Blanket Placement

    2100 Millennium INCORRECT POSITIONS H. Correct Baffle & Blanket Placement WARNING Fire Risk. Firebox damage due to improper baffle placement is not covered by warranty. Operate the wood burning appliance with the baffle in the correct position only. Not doing so could result in: •...

  • Page 15: Blower Operating Instructions

    J. Opacity (Smoke) I. Blower Operating Instructions This is the measure of how cleanly your appliance is NOTE: If your Quadra-Fire wood appliance is equipped burning. Opacity is measured in percent; 100% opacity is with an optional blower, you should follow these...

  • Page 16: Clear Space

    2100 Millennium K. Clear Space L. Negative Pressure • Do NOT place combustible objects within 4 ft (1.2 m) of WARNING the front of appliance (Figure 16.1). • Mantel - avoid placing candles and other heat-sensitive Asphyxiation Risk. objects on mantel or hearth. Heat may damage these •...

  • Page 17: Frequently Asked Questions

    2100 Millennium M. Frequently Asked Questions ISSUES SOLUTIONS When first operated, this appliance may release an odor for the first several hours. This is Odor from appliance caused by the curing of the paint and the burning off of any oils remaining from manufacturing. Noise is caused by metal expanding and contracting as it heats up and cools down, similar to Metallic noise the sound produced by a furnace or heating duct.

  • Page 18: Maintenance And Service

    2100 Millennium Maintenance and Service A. Quick Reference Maintenance Guide CAUTION! Allow the appliance to completely cool down before performing any cleaning or maintenance. When properly maintained, your fireplace will give Start the first inspection after the first 2 months of use, you many years of trouble-free service.

  • Page 19: General Maintenance

    2100 Millennium B. General Maintenance 2. Cleaning Plated Surfaces • Frequency: Prior to first burn and then as desired 1. Creosote (Chimney) Cleaning • By: Homeowner • Frequency: Every 2 months during heating season or Clean all the fingerprints and oils from plated surfaces as recommended by a certified chimney sweep;...
  • Page 20 2100 Millennium 1. Glass Cleaning • Frequency: As desired • By: Homeowner Clean glass with a non-abrasive glass cleaner. Abrasive cleaners may scratch and cause glass to crack. If the deposits on the glass are not very heavy, normal glass cleaners work well.

  • Page 21: Troubleshooting Guide

    2100 Millennium Troubleshooting Guide With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a problem and the corrective action to be taken.

  • Page 22: Service Part Replacement

    9. Replace the door on the appliance. 2. A magnet holds the bracket to the appliance. Pull the bracket down away from the appliance to expose the Quadra-Fire appliances are equipped with ceramic super snap disc. heat-resistant glass, which can only be broken by impact or 3.

  • Page 23: Door Handle Assembly

    2100 Millennium D. Door Handle Assembly 1. Install washer on door handle shaft. 2. Slide door handle through door. 3. Install second washer(s) as shown in Figure 23.1. 4. Install key in groove. 5. Align groove in latch cam with key; slide latch cam over shaft 6.

  • Page 24: Tube Channel Assembly Replacement

    2100 Millennium F. Tube Channel Assembly Replacement Removing Tube Channel Assembly 1. Remove the right side shield by removing 2 screws in the back using a Phillips head screw driver. 2. Remove 4 screws from channel access cover and remove cover. 3.

  • Page 25: Reference Materials

    2100 Millennium Reference Materials A. Service and Maintenance Log Date of Service Performed By Description of Service August 13, 2018 7039-177C...

  • Page 26: Exploded View

    2100 Millennium B. Exploded View 21M-ACC Service Parts 2100 Millennium Wood Stove Beginning Manufacturing Date: July 2007 Advanced Combustion Control (ACC) Ending Manufacturing Date: Active Part number list on following pages. 08/18 7039-177C August 13, 2018...

  • Page 27: Service Parts

    2100 Millennium 21M-ACC Service Parts Beginning Manufacturing Date: July 2007 C. Service Parts Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement Stocked parts for your appliance please provide model number and serial number. All parts listed in this manual may be ordered from an authorized dealer.
  • Page 28 2100 Millennium 21M-ACC Service Parts Beginning Manufacturing Date: July 2007 Ending Manufacturing Date: Active # 16 Burn Rate Control Assembly #17 Door Assembly #18 Baf e Protection Channel Side view 16.10 16.1 16.9 Front, looking into unit 17.1 16.2 17.2 16.8...

  • Page 29: Accessories

    DESCRIPTION COMMENTS PART NUMBER Component Pack (Includes Gold Spring Handles (1) 1/2" For Black & Gold 436-5350 & (2) 1/4", (2) Gold Hinge Pins, Quadra-Fire Logo Doors Gasket, Glass Tape 5 FT 832-0460 Rope, Door, 3/4” X 84” 7 Ft...
  • Page 30 Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL...
