Dimensions and Clearances

A. Appliance Dimensions
12-11/16 in.
(321mm)
9-5/16 in.
(237mm)
Figure 7.1 Top View
20-3/4 in. (528mm)
17-1/4 in. (438mm)
22-1/16 in.
(560mm)
6-5/8 in.
(168mm)
Figure 7.4 - Side View
May 14, 2015
16-1/4 in.
(413mm)
9-15/16 in.
(252mm)
29-1/16 in.
(738mm)
13-7/16 in.
(342mm)
o
15
18-11/16 in.
(475mm)
3-1/16 in.
(78mm)
23-7/8 in.
(606mm)
NOTE: Flue Collar size is 6 inch (152mm) diameter (ID)
Figure 7.2 Front View
Surround Sizes
Standard
Large
13-9/16
344mm
Vertical
Figure 7.3 - Side View With Optional 15 degree Adapter
7046-192C
2700 I-ACC
A
A
43 in. (1092mm) 31 in. (787mm)
51 in. (1346mm) 34 in. (864mm)
20-15/16
14-5/8
532mm
371mm
30 degree
B
B
o
30
20-11/16
525mm
