The D-Series C is shipped from the factory in one of two configurations, either

dome up or dome down, depending on the model ordered. Confirm that the

camera matches the intended installation.

All connections are made via the attached pigtail cable assembly.

•

Ensure that all pigtail connections are made inside a water-tight enclosure.

Caution!

Before installing the D-Series C camera be sure to read and understand the

following documents which provide details regarding mechanical dimensions

and installation safety. These documents are available on the CD or from the

FLIR web site.

•

D-Series C Installation Manual (FLIR Doc # 427-9030-01-12)

•

D-Series C Interface Control Document (FLIR Doc # 427-9XXX-XX-19)

427-9030-01-28 Rev 110

Quick Connect Guide

D-Series C

Mar 2014

Table of Contents

Do you have a question about the D-series C and is the answer not in the manual?

Page 1: Quick Connect Guide
Quick Connect Guide D-Series C Installation Overview The D-Series C is shipped from the factory in one of two configurations, either dome up or dome down, depending on the model ordered. Confirm that the camera matches the intended installation. All connections are made via the attached pigtail cable assembly.
Page 2: Camera Mounting
Caution! Do not disassemble the D-Series C camera. Damage to the camera can occur as the result of careless handling or electrostatic discharge (ESD). Prior to making any connections, ensure the power is switched off. Camera Mounting The camera can be attached to the mount with a single 1.5” NPT stainless steel threaded coupler which is supplied with the camera.
