2. Accessories

The following accessories are included.
Wood screw +
wall plugs Small screw
(Ø3.5×16)
2x
2x
3. Remote controller installation
procedure
3-1 Determine where to install the remote controller.
Make sure to follow
3-2 Make a wiring through hole on the wall if the wires are
coming out from the rear.
Lower case
Through hole
BRC2E52C7 / BRC3E52C7
–
4P368041-1 2014.02
Clamp
(M4×16)
2x
"1. Safety Precautions"
40
Through
hole
Ø 8-10
Wiring retainer
1x
1x
when determining the location.
External view of the remote controller
Ø 8-10
Set the center of the wall hole
to the center of the wiring
through hole on the controller
lower case when making the
hole.
48.5
CAUTION
If the hole size is too large or the location is not
proper, the hole may come out from the
controller.
Accessories
Installation manual
4
