Access to Maintenance and Personalization Data

4.1 Display Organization

4.2 Access to Measurements

Press the scroll button (25) to access measurements for voltage, current, frequency, power output and battery capacity.

4.3 Access to UPS Set-Up and Maintenance Using the Control Panel (23)

86-87050-00 A01
Status and Alarms
Measurements
UPS input measurements
UPS output measurements
Battery measurements
UPS Set-up
Local settings
Output settings
ON/OFF settings
Battery settings
Access to Maintenance and
Personalization Data
Maintenance
Model
Alarm History
Manual battery test
Led and Buzzer test
LCM
Statistics
Operation limits
◗ Press the scroll button (25) a number of times to
point to the UPS set-up or Maintenance menu.
◗ Press the "Enter" button (27) to get access.
4 — 1
