Pulsar MX
1.5

Extended Battery (EXB)

Pulsar MX RT offers a standard backup time of 5 minutes at full load. To increase backup time, it is possible to connect
Pulsar MX EXB RT modules to the UPSs for backup times up to 62 minutes (at full load).
Battery extensions for Pulsar MX RT
Pulsar MX
5000 RT
Pulsar MX 5000 RT:
Battery Integration System Kit with Casters (86005)
Optional battery extension cable (6 ft/1.8 m)
This extended battery cable will be used instead of the standard battery cable when battery modules are distant from each
other (located in two different enclosures, for instance).
1 — 4
Pulsar MX
EXB RT
5 min 22 min
Presentation
Pulsar MX Pulsar MX
EXB RT EXB RT
41 min 62 min
The Battery Integration System is intended
for extended backup time configurations
to conveniently stack and secure up to 5
modules on the same cart (swivel wheels
with brakes, leveling feet, seismic side
panels, plates to lock modules, and screws
included).
86-87050-00 A01
