- Page 1 www.mgeups.com SYSTEMS Pulsar Evolution 1500 / 1500 Rack 1100 / 1100 Rack / 800 Rack 500 Rack Installation and user manual - Page 1 34007117EN/AB...
- Page 2 Page 2 - 34007117EN/AB...
- Page 3 Pulsar Evolution at the end of its service life. To discover the entire range of MGE UPS SYSTEMS products and the options available for the Pulsar Evolution range, we invite you to visit our web site at www.mgeups.com or contact your MGE UPS SYSTEMS representative.
- Page 4 Foreword Using this document Information may be found in two ways, using: the contents; the index. Pictograms Important instructions that must always be followed. Information, advice, help. Visual indication. Action. Audio indication. In the illustrations on the following pages, the symbols below are used: LED off.
-
Page 5: Table Of Contents
Contents Presentation Overall view ..........................7 Tower models ..........................7 Rack models ........................... 7 Back ............................. 8 Control panel ..........................9 Installation Unpacking and parts check ....................... 10 Tower models ..........................10 Rack models ..........................11 Installation ........................... 12 Tower models ..........................12 800/1100/1500 Rack models ...................... - Page 6 Contents Maintenance Trouble-shooting ......................... 22 Replacement of the battery module ..................23 Tower models ..........................23 Rack models ..........................25 Environment ............................. 27 Appendices Technical data ..........................28 Simplified diagram ........................26 Technical characteristics ....................... 29 Examples of battery backup times ....................30 Glossary ............................
-
Page 7: Presentation
1. Presentation 1.1 Overall view Tower models Dimensions in mm (W x H x D) Evolution 800 150 x 237 x 415 Evolution 1100 150 x 237 x 415 Evolution 1500 150 x 237 x 483 Weight in kg Evolution 800 10.5 Evolution 1100 11.5... -
Page 8: Back
Slot for communications-card option. Outlets for direct connection of protected equipment. Programmable outlets (1 and 2). Input circuit-breaker. Socket for connection to AC-power Pulsar Evolution 500 / 800 / 1100 Rack source. Pulsar Evolution 1500 Rack Page 8 - 34007117EN/AB... -
Page 9: Control Panel
1. Presentation 1.3 Control panel Iluminated ON/OFF button for the outlets. Operation on battery power. UPS fault. Battery fault. Overload. Group 1 programmable outlets supplied with power. Group 2 programmable outlets supplied with power. Booster or fader mode. Bargraph indicating percent load at output. Bargraph indicating the battery charge level. -
Page 10: Unpacking And Parts Check
2. Installation 2.1 Unpacking and parts check Tower models io n lu t E v o Two cords for connection of the protected equipment. RS232 communications cable. USB communications cable. CD-ROM with the Solution-Pac and UPS Driver software. Product documentation. Page 10 - 34007117EN/AB... -
Page 11: Rack Models
2. Installation Rack models Two cords for connection of the protected equipment. RS232 communications cable. USB communications cable. CD-ROM with the Solution-Pac and UPS Driver software. Product documentation. Telescopic rails for mounting in 19" bay with mounting hardware. Securing system for equipment power cords. - Page 11 34007117EN/AB... -
Page 12: Installation
2. Installation 2.2 Installation Tower models io n lu t E v o Page 12 - 34007117EN/AB... -
Page 13: 800/1100/1500 Rack Models
2. Installation 800/1100/1500 Rack models Follow steps 1 to 6 for rack mounting of the UPS on the rails. The rails and the necessary mounting hardware are supplied by MGE UPS SYSTEMS. - Page 13 34007117EN/AB... -
Page 14: 500 Rack Model
2. Installation 500 Rack model Page 14 - 34007117EN/AB... -
Page 15: Connecting The Protected Equipment
2. Installation 2.3 Connecting the protected equipment A Pulsar Evolution 1500 tower UPS has been used below to illustrate the instructions. The principle is the same for all the other tower and rack models. Check that the indications on the rating plate on the back of the UPS correspond to your AC-power system and to the actual electrical consumption of all the equipment to be connected to the UPS. -
Page 16: Connection To The Rs232 Or Usb Communications Port (Optional)
2. Installation A Pulsar Evolution 1500 tower UPS has been used below to illustrate the instructions. The principle is the same for all the other tower and rack models. 2.4 Connection to the RS232 or USB communications port (optional) The RS232 and USB communications ports cannot operate simultaneously. -
Page 17: Installation Of The Communications-Card Option
2. Installation 2.6 Installation of the communications-card option 1 - Remove the slot cover 4 secured by two screws. Restricted-access slot for 2 - Insert the card in the slot. the communications card 3 - Secure the cover with the two screws. RS232 DATA LINE PROTECTION It is not necessary to shut down the UPS to install the communications card. -
Page 18: Operation Start-Up
3. Operation 3.1 Start-up Press the ON / OFF button 10 . The buzzer beeps and all the LEDs come ON. The buzzer beeps twice during the self-test, then button 10 remains ON, indicating that the outlets are supplied with power. - AC power is present: Only button 10 is ON. -
Page 19: Operation On Battery Power (Following Failure Of Ac-Input Power)
3. Operation 3.3 Operation on battery power (following failure of AC-input power) Transfer to battery power The AC-input power is out of tolerances, LED 11 goes ON. During operation on battery power, the buzzer beeps every ten seconds. The equipment connected to the UPS is supplied by the battery. Threshold for the low-battery warning When the threshold is reached, the buzzer beeps every three seconds. -
Page 20: Personalisation (Optional)
3. Operation 3.4 Personalisation (optional) Function Personalisation parameters can be set and modified using the UPS Driver software installed on a computer that is connected to the UPS (see section 2.4 Connection to the RS232 communications port). Check that the RS232 21 communications cable is connected. UPS Driver installation: 1 - Insert the Solution-Pac CD-ROM containing the UPS Driver software in the drive of a PC running Windows. -
Page 21: Voltage-Thresholds Tab
3. Operation Voltage-thresholds tab Configurable function Default setting Options Output voltage on battery power 230 V 200 V - 220 V - 240 V Upper threshold for transfer to battery power 294 V 271 to 294 V Fader-mode cut-in threshold 265 V 244 to 265 V Booster-mode cut-in threshold... -
Page 22: Maintenance Trouble-Shooting
4. Maintenance 4.1 Trouble-shooting Troubleshooting not requiring MGE UPS SYSTEMS after-sales support (all versions) Indication Signification Correction LED 13 flashes and the UPS overload. The power drawn by the connected Check the power drawn by the buzzer beeps once. equipment exceeds UPS capacity. -
Page 23: Replacement Of The Battery Module
4. Maintenance 4.2 Replacement of the battery module Safety rules Batteries constitute a danger (electrical shock, burns). The short-circuit current may be very high. Precautions must be taken for all handling: remove all watches, rings, bracelets and any other metal objects; use tools with insulated handles. - Page 24 4. Maintenance E - Remove the battery module by pulling on the plastic tab and proceed with replacement. Installation of the new battery module Carry out the above operation in reverse order. Caution: risk of electric arc when connecting the battery. To maintain an identical level of performance and safety, use a battery module identical to that previously mounted in the UPS.
-
Page 25: Rack Models
4. Maintenance Rack models Removal of the battery module This operation may be carried out with the UPS supplying power to the load. A - Unclip the small plate with the MGE logo on the front panel of the UPS. B - Remove the two screws. - Page 26 4. Maintenance E - Remove the cover. F - Remove the battery module by pulling on the plastic tab and proceed with replacement. Installation of the new battery module Carry out the above operation in reverse order. Caution: risk of electric arc when connecting the battery. To maintain an identical level of performance and safety, use a battery module identical to that previously mounted in the UPS.
-
Page 27: Environment
UPS recycling at the end of service life: MGE UPS SYSTEMS undertakes to recycle, by certified companies and in compliance with all applicable regulations, all UPS products recovered at the end of their service life (contact your MGE branch office). -
Page 28: Technical Data
6. Appendices 6.1 Technical data Simplified diagram Filter Booster / fader transformer Input Output Inverter Charger Battery Page 28 - 34007117EN/AB... -
Page 29: Technical Characteristics
6. Appendices Technical characteristics Pulsar Evolution 1500 / 1500 rack 800 / 800 rack 1100 / 1100 rack 500 VA / 350 W 1500 VA / 1000 W Output rating 800 VA / 560 W 1100 VA / 700 W AC-input power Voltage Single-phase, 160 V to 294 V... -
Page 30: Examples Of Battery Backup Times
1 data server + 1 hub + 1 router 1 router 1 hub 110 120 t (min) Pulsar Evolution 1500 5 rack-optimized dense servers 3 file/print servers 2 data servers + 1 hub + 1 router 1 router 110 120... -
Page 31: Glossary
UPS. RS232 communications port For UPS connection to a computer via the serial port. Solution-Pac MGE UPS SYSTEMS safety, set-up and supervision software suite on the CD-ROM supplied with the UPS. Uninterruptible Power Supply. UPS Driver Communications software on the CD-ROM supplied with the UPS. It may be used to personalise the default settings. -
Page 32: Index
6. Appendices 6.3 Index Automatic start ............... 20 Mode Booster mode ............. 9, 18 Fader mode ............9, 18 Sleep mode (automatic start) ......... 20 Bargraph ................9 Battery Backup time ............30 End of backup time ..........19 Overloads ..............9, 22 Fault .................
