- Page 1 ИБП MGE Pulsar EXtreme - Pulsar EXtreme CLA 2000 - 3000 ВА - Руководство Постоянная ссылка на страницу: https://eaton-power.ru/catalog/mge-pulsar-extreme/...
- Page 2 MGE UPS SYSTEMS www.mgeups.com Pulsar EXtreme CLA 2000/3000 VA Installation manual - Page 1 51033775EN/AA...
- Page 3 Page 2 - 51033775EN/AA...
- Page 4 1. Unpacking ... and checking the contents Pulsar EXtreme CLA 2000/3000 VA Tower model Rack model Pulsar EXtreme CLA module. documentation. connection cable. telescopic rails and 19" rack mounting hardware. - Page 3 51033775EN/AA...
-
Page 5: Installation
2. Installation 2.1 Mounting (Rack model) Mounting the rails in the rack. The rails and the screws required to mount them are included in the box. Page 4 - 51033775EN/AA... - Page 6 2. Installation 2.2 Checking equipment compatibility Check that the UPS and CLA modules are compatible: UPS no. CLA no. Pulsar EXtreme CLA 2000 51033021 51033029 Pulsar EXtreme CLA 3000 51033031 51033539 Pulsar EXtreme CLA 2000 Rack 51033529 51033521 Pulsar EXtreme CLA 3000 Rack 51033539 51033531 2.3 Batteries to be used...
- Page 7 2. Installation Use a 3-conductor cable (shielded, max. length 6 m, 3 x 4 mm conductors) to be passed through the shielded cable gland. 2 5 A Use a 25 A circuit breaker (curve B) for protection. Note: the cable and circuit breaker are not supplied with the product.
- Page 8 2. Installation 2.6 Connecting the UPS to the Pulsar EXtreme CLA module Use the connection cable supplied with the module. 2.7 Setting the UPS Before connecting the loads to be protected and starting the system, the UPS must be reconfigured using the UPS Driver software supplied on a diskette with the UPS.
-
Page 9: Technical Specifications
3. Technical specifications Dimensions and weights Pulsar EXtreme CLA Dimensions in mm (H x W x D) Weight in kg Tower model 443 x 173 x 465 Rack model 177(4U) x 483 x 462 Operating voltage and frequency of the Pulsar EXtreme CLA Voltage: 160 to 260 V.
