DIP Switch
BSP
Jumbo Frame
802.3az
100/1000BaseSFP
Port Alarm
ATTENTION
To actively update DIP switch settings, power off and then power
on the switch.

LED Indicators

The front panel of the EDS-G205-1GTXSFP switch contains several LED
indicators. The function of each LED is described in the table below.
LED Color
PWR1 AMBER
PWR2 AMBER
FAULT RED
AMBER
10/100/
1000M
GREEN
Setting Description
ON Enables broadcast storm protection
OFF Disables broadcast storm protection
ON Enables jumbo frame function
OFF Disables jumbo frame function
Enables the energy-efficient Ethernet
ON
function
Disables the energy-efficient Ethernet
OFF
function
ON Supports 100M SFP module
OFF Supports 1000M SFP module
Enables the corresponding PORT
Alarm. If the port's link fails, the relay
ON
will form an open circuit and the fault
LED will light up
Disables the corresponding PORT
Alarm. If the port's link fails, the relay
OFF
will form a closed circuit and the fault
LED will never light up
State Description
Power is being supplied to power input
On
PWR1
Power is not being supplied to power input
Off
PWR1
Power is being supplied to power input
On
PWR2
Power is not being supplied to power input
Off
PWR2
When the corresponding PORT alarm is
On
enabled, and the port's link is inactive.
When the corresponding PORT alarm is
enabled and the port's link is active, or
Off
when the corresponding PORT alarm is
disabled.
TP port's 10/100 Mbps or SFP port's 100
On
Mbps link is active.
Blinking Data is being transmitted at 10/100 Mbps
TP port's 10/100 Mbps or SFP port 100
Off
Mbps link is inactive.
On TP/SFP port's 1000 Mbps link is active.
Blinking Data is being transmitted at 1000 Mbps
Off TP/SFP port's 1000 Mbps link is inactive
