SATA RAID Setup - UEFI Enabled
To configure your RAID (Redundant Array of Independent Disks) system in Strip-
ing (RAID 0) or Mirroring (RAID 1) modes (see
require two identical hard disks or solid state drives.
You need to setup a RAID before installing your Windows 10 operating system, and
you will need to prepare the following in order to do so.
==========================================================
• The Microsoft Windows 10 OS DVD.
• An attached external DVD drive.
• A hard disk installed in the Primary HDD bay and a second (identical) hard disk
installed in the Secondary HDD bay.
OR
Two Identical solid state drives.
• The Device Drivers & Utilities + User's Manual disc.
==========================================================
1.
Start-up your notebook computer and press <F2> to enter the BIOS.
2.
Go to the Boot menu, select UEFI Setting and press <Enter> (see page
3.
Set UEFI Boot to "Enabled".
4.
Press <Esc> to exit the menu and go to the Advanced menu.
5.
Select SATA Mode (see page
6.
Press <F4> and <Yes> to "Save Changes and Reset".
7.
As the computer restarts press <F2> to enter the BIOS again.
8.
Go to Intel(R) Rapid Storage Technology (Advanced menu) and press <Enter>.
Table 6 - 1, on page 6 -
5 -
12), press <Enter> and select "RAID Mode".
Setting Up SATA RAID or AHCI Mode 6 - 5
3) you will
5 -
18).
