- Page 1 AT-PRO130HD MANUAL www.atlona.com...
-
Page 2: Operation Notice
This manual is only for operational instruction, not for any maintenance service. The manufacturer will make a supplement for any function or parameter revision. The copyright of AT-PRO130HD USER MANUAL belongs to the manufacturer, any company or individual uses part of, or all content of the manual for any commercial purpose without the consent of manufacturer is prohibited. - Page 3 Features The AT-PRO130HD is a Seamless scaler/switcher designed for multi-signal processing, Composite VIDEO, S-VIDEO, VGA and HDMI can be scaled to high-resolution VGA or HDMI formats. * Composite video, S-Video, VGA and HDMI can be switched to VGA or HDMI outputs with the following...
- Page 4 Under power-off status, pressing MUTING continuously while resuming power supply to enter back light setting mode, setting range is 0-99 minutes. • 8. Master vol adjustment. with LCD and bar indicator. • 9. Power status indication • 10. IR Sensor • 10. MIC Rear Panel www.atlona.com...
-
Page 5: Remote Control
Remote control: Functions are the same as of the front panel. 1 Model and Channel choosing Using remote to choose channels 2 Resolution choosing SVGA,XGA,SXGA --3 types of resolution: SVGA 800×600 @75Hz 1024×768@60Hz SXGA 1280×1024@60Hz 3 MIC volume adjust www.atlona.com... - Page 6 Video brightness 00--99% (0< xx <100) xx$03! select the Video Contrast 00--99% (0< xx <100) xx$04! select the Video Saturation 00--99% (0< xx <100) xx$05! select the S-Video brightness 00--99% (0< xx <100) xx$06! select the S-Video Contrast 00--99% (0< xx <100) www.atlona.com...
- Page 7 +, parameter -. function_2: 2 SV Contrast, Contrast adjustment, works with parameter +, parameter -. function_3: 3 SV Saturation, Saturation adjustment, works with parameter +, parameter -. function_4: 4 RESTORE SV DEFAULT VALUE?, works with ENTER. Resets back to default. www.atlona.com...
- Page 8 AT-PRO130HD specification Video Gain 0 dB Bandwidth AV video:150MHz, S-video video:150MHz,VGA video:375 MHz. Multi-channel -50dB @50 MHz, -45dB @10 MHz input :one-channel DC phase/OS <1.28 Degree,3.58 MHz DC phase deviation 0.1%,3.58-4.43 MHz DC gain deviation 0.1 Degree, 3.58-4.43 MHz...
- Page 9 AT-PRO130HD specification Audio signal Input/output 8-channel RCA imbalance input,4-channel 3.5mm imbalance output connector Gain 0 dB Frequency 20 Hz ~ 20 kHz, response Total harmonic 0.05% @ 1 kHz (rating voltage) component lost and noise (S/N ) >8dB Stereo separation >80dB @ 1 kHz...
-
Page 10: Troubleshooting
10) If the scaler cannot be controlled by the buttons on the front panel, RS232 port or remote control, the scaler may have broken. Please contact the manufacture for repair/ replacement. www.atlona.com... -
Page 11: Limited 3-Year Warranty
ATLONA warrants only to the initial purchaser of this product for a period of three years from the date of purchase from an Authorized ATLONA Reseller, the product will be free of electri- cal and mechanical defects that materially affect the products operation as described in this users manual.
