- Page 1 User Manual AtlonA COMPOSITE VIDEO (BNC) + STEREO AUDIO TO HDMI VIDEO FORMAT CONVERTER AND SCALER AT-HD120 Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515...
-
Page 2: Table Of Contents
3. Features ..........4. Specification ..........5. Panel Description ..........5.1. Front Panel ..........5.2. Rear Panel ..........6. Connection and Operation ..........7. Atlona Product Registration ..........8. Safety Information ..........9. Warranty ..........Toll free: 1-877-536-3976 atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
INTRODUCTION The Atlona AT-HD120 easily converts and scales a composite video (BNC) signal from a DVD, VCR or camcorder to an HD display. It supports resolutions up to 1080p and 1600 X 1200 (UXGA). The Atlona AT-HD120 also supports the conversion from NTSC to PAL or PAL to NTSC. -
Page 4: Panel Description
5.2. Rear Panel 1. Composite video (BNC) in: Connect the input port of the AT-HD120 to the output port of a source such as a VCR or DVD. Use the included BNC to RCA adaptor when using a cable with an RCA connector. -
Page 5: Connection And Operation
3. Connect the supplied power supply to the AT-HD120 and into an A/C wall receptacle 4. If connected to a computer monitor select PC mode from the dip switch on the AT-HD120. If con- nected to an HDTV or projector select HD mode. -
Page 6: Safety Information
It may also cause damage to your the manufacturer could void the AT-HD120. Opening the product will void the user’s authority to operate this warranty. equipment. -
Page 7: Warranty
Atlona requires that products returned are properly packed, preferably in the original carton, for shipping. Cartons not bearing a return authorization or case number will be refused. Atlona, at its sole discretion, reserves the right to reject any products received without advanced authorization. Authorizations can be requested by calling 1-877-536-3976 (US toll free) or 1-408- 962-0515 (US/international) or via Atlona’s website at www.atlona.com. -
Page 8: Atlona Product Registration
Atlona’s products may be used in conjunction with. Atlona, at its sole discretion, reserves the right not to extend its warranty offering in instances arising outside its normal course of business including, but not limited to, damage inflicted to its products from acts of god.
