CyberData 011113 series Operation Manual page 43

Web Page Item
Call Button
ID
Security Code (0 through 9)
Misc Settings
Play Button Tone
3. After changing the parameters, click the Save button.
Operations Guide
Table 2-11. Button Configuration Parameters (continued)
Description
Enter the desired dial-out extension number (64 character
limit). Security codes are limited to seven characters and
are activated with the # key.
Note: For information about dial-out extension strings and
DTMF tones, see
Strings and DTMF Tones (using
Type the desired Extension ID (64 character limit).
Enter the desired security code number (7 character limit).
When a security code is entered on the keypad that
matches one of the seven-digit fields specified on the
page, the relay will be activated.
Check this box to hear a tone when a keypad button is
pushed. This setting applies to all modes and determines
whether the device will play an audible sound out of the
speaker when doing any of the following:
• Entering a security code
• Initiating a speed dial
• Pressing the keys in cellphone and telephone modes
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
930323L
Installing the VoIP Indoor Intercom with Keypad
Section 2.3.6.1, "Dial Out Extension
rfc2833)".
CyberData Corporation
37
