8. FINISHING THE INSTALLATION

Step 1. Move fan into position over the four
mounting studs and secure with the provided
washers and nuts. (Fig. 10)
Step 2. Raise the motor housing up against
the mounting plate, the four supports inside
the housing should be placed against the four
studs on mounting plate, twist the housing
clockwise until snug. (Fig. 11)
Windham
Screws
Washers
Nuts
Fig. 10
Studs
Motor
housing
Fig. 11
TM
6
