Summary of Contents for Kichler Lighting Windham
-
Page 2: Safety Rules
1. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. WARNING: Use only with light kit marked electricity has been turned off at the circuit "Suitable for Use in Damp Locations". breaker or fuse box before beginning. 9. -
Page 3: Tools And Materials Required
Windham 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Mounting plate... -
Page 4: Mounting Options
4. MOUNTING OPTIONS If there isn't an existing UL (CUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers Secure the outlet box directly to the building Outlet box structure. -
Page 5: Hanging The Fan
Windham 5. HANGING THE FAN REMEMBER to turn off the power. Follow the CUL Listed electrial steps below to hang your fan properly: Step 1. Attach the mounting plate to the outlet box with two screws and washers provided with the outlet box. Make sure the mounting plate is tight and secured. -
Page 6: Make The Electric Connections
7. MAKE THE ELECTRIC CONNECTIONS Power lines 120v Green ground Remember to disconnect the power. Follow the steps below to connect the fan to your household wiring. Use the wire Wiring connecting nuts supplied with your fan. Secure the connectors with electrical tape. Ground to mounting Make sure there are no loose strands or... -
Page 7: Finishing The Installation
Windham 8. FINISHING THE INSTALLATION Step 1. Move fan into position over the four mounting studs and secure with the provided washers and nuts. (Fig. 10) Screws Step 2. Raise the motor housing up against the mounting plate, the four supports inside... -
Page 8: Attaching The Fan Blades
9. ATTACHING THE FAN BLADES Step 1 Attach the blade to the blade bracket using the screws, washers and rubber washers as shown in Figure 12. Start screw into bracket. Repeat for the two remaining screws. Screws Step 2 Make sure the blade is straight and Washers tighten each screw. -
Page 9: Installing The Light Kit
Windham 11. INSTALLING THE LIGHT KIT NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. - Page 10 13. OPERATING INSTRUCTIONS Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1. 3-speed pull chain- it controls the fan speed as follows: 1 pull- High, 2 pulls- Medium, 3 pulls- Low, and 4 pulls- Off.
-
Page 11: Troubleshooting
Windham 14. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds noisy.
