Kichler
Lighting
®
7711 East Pleasant Valley Road
P.O. Box 318010
Cleveland, Ohio 44131-8010
Customer Service
866.558.5706
8:30 AM to 5:00 PM EST,
Monday - Friday
Designed to coordinate with a popular Kichler Lighting collection.
Includes our new
CoolTouch
Control System
TM
Looks permanent, but goes wherever you go!
U.S. Patent Pending
Instruction Manual
Wilton
TM
A Kichler
®
Décor
ceiling fan

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wilton and is the answer not in the manual?

Questions and answers

Summary of Contents for Kichler Lighting Wilton

  • Page 1 Wilton A Kichler ® Décor ™ ceiling fan Designed to coordinate with a popular Kichler Lighting collection. Includes our new CoolTouch Control System Looks permanent, but goes wherever you go! U.S. Patent Pending Kichler Lighting ® 7711 East Pleasant Valley Road P.O.
  • Page 2: Safety Rules

    1. SAFETY RULES 1. To reduce the risk of electric shock, insure 8. Avoid placing objects in the path of the electricity has been turned off at the circuit blades. breaker or fuse box before beginning. 9. To avoid personal injury or damage to the 2.
  • Page 3: Tools And Materials Required

    Wilton 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Slot screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Canopy Mounting bracket Ball/downrod assembly (1) &...
  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing UL ( CUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure.
  • Page 5: Hanging The Fan

    Wilton 5. HANGING THE FAN REMEMBER to turn off the power. Follow the Screw steps below to hang your fan properly: Shipping block Step 1. Remove the fan motor and housing assembly from the protective plastic bag. Place the fan assembly into the lower pad with the bottom of the motor facing up.(The...
  • Page 6 Step 6. Slip the coupling cover, canopy cover Supply wires and canopy onto the downrod. Carefully reinstall the hanger ball onto the downrod. Make sure the cross pin is in the correct Canopy position and the set screws are tight and the wires are not twisted.
  • Page 7: Installation Of Safety Support

    Wilton 6. INSTALLATION OF SAFETY SUPPORT ( For Canadian Installation ONLY ) An additional safety support is provided to prevent the fan from falling. Secure the safety Safety cable Hanger bracket cable to the ceiling joist with screw and washer, as illustrated in Figure 11.
  • Page 8 Step 3. Remote Receiver to Outlet Box Electri- Outlex box cal Connections: Connect the black (hot) wire from the ceiling to the black wire marked “AC in White (neutral) Black (hot) L” from the receiver. Green or bare Connect the white (neutral) wire from the ceil- ing to the white wire marked “AC in N”...
  • Page 9: Attaching The Fan Blades

    Wilton 9. ATTACHING THE FAN BLADES Screw Step 1 Attach the blade to the blade bracket using the screws, washers and fiber washers Metal washer as shown in Figure 16. Start screw into Silicon washer Blade bracket. Repeat for the three remaining screws.
  • Page 10: Installing The Switch Housing

    11. INSTALLING THE SWITCH HOUSING NOTE: The wire connectors in this step will only fit together “One Way”. Make sure the connectors are properly aligned. Step 1. Loosen the 3 screws on the switch housing mounting plate. Step 2. The square plastic wiring connector from the ceiling fan and the switch housing AMP connnection will only fit together one way.
  • Page 11 Wilton Step 5. The square plastic wiring connector from the ceiling fan and the light fixture will only fit together one way. Match up the color on the side of the connector, then push them together until the snap engages.
  • Page 12 14. OPERATING INSTRUCTIONS Restore power to ceiling fan and test for proper operation. , and buttons: These three buttons are used to set the fan speed as follows: = low speed = medium speed = high speed button: This button turns the fan off. Fig.
  • Page 13: Installing The Cooltouchâ„¢ Control System Wall Plate

    Wilton 15. INSTALLING THE CoolTouch™ Ou t l et b o x Sw i t c h CONTROL SYSTEM WALL PLATE Wal l p l at e To install the coolTouch control system wall plate, you can select the following locations to fulfill your wall plate installation.
  • Page 14: Troubleshooting

    17. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check circuit fuses or breakers. 2. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. 3. Check to make sure the dip switches from the transmitter and receiver are set to the same frequency.
