Equipment and service options
Connect through an adapter used in your area
Connect to a computer with a modem

Connecting to an analog telephone line

If your telecommunications equipment uses a US-style (RJ11) telephone line, then follow these steps to connect the
equipment:
1
Connect one end of the telephone cable that came with the printer to the top LINE port
printer.
2
Connect the other end of the telephone cable to an active analog telephone wall jack.

Connecting to a DSL service

If you subscribe to a DSL service, then contact the DSL provider to obtain a DSL filter and telephone cord, and then
follow these steps to connect the equipment:
1
Connect one end of the telephone cable that came with the printer to the top LINE port
printer.
2
Connect the other end of the telephone cable to the DSL filter.
Note: Your DSL filter may look different than the one in the illustration.
3
Connect the DSL filter cable to an active telephone wall jack.
Fax connection setup
See "Connecting to an adapter for your country or region"
on page 93.
See "Connecting to a computer with a modem" on
page 98.
Faxing
90
on the back of the
on the back of the
