Figure 4-23 I/O Board Assembly Removal And Replacement - HP Integrity rx6600 User's & Service Manual

NOTE
Figure 4-23 I/O Board Assembly Removal and Replacement
Rear Chassis View
Chapter 4
The I/O board assembly is large. Use care when lifting it out of the server chassis.
Removal and Replacement
Removing and Replacing the I/O Board Assembly
Retention Latches
Extraction Levers In
the Unlocked Position
