Figure 1: Browser interface (Live view shown)
Parameters
1.
Live View
2.
Playback
3.
Log
4.
Configuration
5.
Current User
6.
Logout
7.
PTZ Controls
8.
Aspect Ratio
9.
Live View Mode
10.
Start/stop Live View
11.
Audio
12.
Viewer
13.
Bidirectional Audio
14.
Capture
15.
Start/stop Recording
16.
Digital Zoom
6
Description
Click to view live video.
Click to playback video.
Click to search for event logs. There are three main types:
Alarm, Exception, and Operation.
Click to display the configuration window for setting up the
camera.
Display current user logged on.
Click to log out from the system. This can be done at any time.
Control pan, tilt, zoom actions, set up presets and tour.
Choose the aspect ratio (4×3, 16×9 or auto).
Choose live view mode among 360°, panorama, and (or) PTZ
mode.
Click to start/stop live view.
Adjust volume.
View live video. Time, date and camera name are displayed
here.
Enable/disable bidirectional audio
Click to take a snapshot of the video. The snapshot will be saved
to the default folder in JPEG format.
Click to record live video.
Click to enable digital zoom.
TruVision 360° Camera Configuration Manual
