- Page 1 TruVision 6MP and 12MP 360° Camera Installation Manual P/N 1073656-EN • REV C • ISS 14OCT19...
- Page 2 © 2019 United Technologies Corporation, Copyright Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trade names used in this document may be trademarks or registered trademarks Trademarks and of the manufacturers or vendors of the respective products.
- Page 3 For contact information and to download the latest manuals, tools, and firmware, Contact information go to the web site of your region: and manuals/ tools/ firmware Americas: www.interlogix.com EMEA: www.firesecurityproducts.com Manuals are available in several languages. Australia/New Zealand: www.utcfs.com.au...
-
Page 5: Table Of Contents
Install the camera 6 IR illuminators 9 Accessing the SD card 9 Mounting accessories 10 Using the camera with an Interlogix NVR or another system 11 Using the camera with TruVision Navigator 11 Specifications 13 Pin definitions 14 Installation Manual... -
Page 6: Introduction
Introduction Product overview This is the installation manual for TruVision 6MP and 12MP 360° camera models: Description TruVision 360° IP Dome, 6MP, Indoor, DWDR, 1.29 mm fisheye lens, True D/N, 15m IR, Bi-directional audio (built-in mic & TVF-5201 speaker), Alarm (alarm input and alarm output), SD/SDHC slot, PoE + (802.3-at) /12 VDC, Gray TruVision 360°... -
Page 7: Contact Information And Manuals/Tools/Firmware
Contact information and manuals/tools/firmware For contact information and to download the latest manuals, tools, and firmware, go to the web site of your region: Americas: www.interlogix.com EMEA: www.firesecurityproducts.com Manuals are available in several languages. Australia/New Zealand: www.utcfs.com.au... - Page 8 Hex wrench 95 x 50mm Screws: Drywall anchor 7.5 x 24.5mm (4 pcs) Screw M4 7 x 25mm (4 pcs) Drill template 12 VDC connector Protective tape Protective water resistant RJ45 connector cover: Provides water (Only for outdoor cameras) resistance to network cable connector Installation manual Equipment disposal sheet...
-
Page 9: Cable Requirements
CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE certified or LPS (limited power source) of the required output rating as listed on the unit. Cable requirements For proper operation, adhere to the following cable and power requirements for the cameras. -
Page 10: Install The Camera
14. Audio in Install the camera Note: If the light source where the camera is installed experiences rapid, wide- variations in lighting, the camera may not operate as intended. To install the 360° camera on a ceiling or wall: Prepare the mounting surface. Use the drill template provided to draw the positions of the screws and cabling hole. - Page 11 Remove the camera cover ring from the camera. Using the hex wrench provided, unscrew the hex head screw located under the small flap on the cover. Using a flathead screwdriver, release the two clips on the base of the camera to release the cover. Grasp the opening on the side of the cover, and pull the cover and base apart to open the camera.
- Page 12 Attach the camera to the ceiling/wall. Align the holes on the base of the camera with the three screws in the ceiling/wall and rotate the camera to lock it into position. When mounting the camera to a wall, ensure that the ‘TOP’ reference is pointing up.
-
Page 13: Ir Illuminators
IR illuminators The camera’s built-in IR illumination provides high-quality video in low-light environments, even when there is no other illumination available. You can configure the IR illumination using a web browser or a client software. If the function is enabled, the IR light is on when the camera enters night (black and white) mode. -
Page 14: Mounting Accessories
Figure 2: Access the micro SD card in the camera Video and log files stored on the micro SD card can only be accessed via the web browser. You can access video from the card using TruVision Navigator or a recording device, but log files must be accessed via the web browser interface. -
Page 15: Using The Camera With An Interlogix Nvr Or Another System
Using the camera with TruVision Navigator A camera must be connected to an Interlogix NVR in order to be operated by TruVision Navigator. Please refer to the TruVision Navigator user manual for instructions on operating the camera with the TruVision Navigator. -
Page 16: Camera Cover
Instructions to remove the TruVision 360° camera cover To remove the TruVision 360° camera cover: Open the small flap on the camera cover. Using the hex wrench provided, loosen the small screw. Two clips on the cover ring lock it on to the camera base. Using a flathead screwdriver, release the two clips on the base of the camera to detach the cover. -
Page 17: Specifications
Note: When the TruVision 360° camera is mounted to the wall or ceiling, you will not have access to the two clips. In such situations, use a flathead screwdriver to gently pry the cover (see step 3 A.1) apart from the camera base. Specifications Electrical 12 VDC ±... -
Page 18: Pin Definitions
Pin definitions There are eight wires on a standard UTP/STP cable and each wire is color- coded. The following shows the pin allocation and color of straight and crossover cable connection: Figure 3: Straight-through cable White/Orange White/Orange Orange Orange White-Green White-Green Blue Blue...
