4-4-2 MAIN-D UNIT VOLTAGE LINE
Line
HV The voltage from a DC power supply.
The same voltage as the HV line which
is controlled by the power switching cir-
cuit (Q23, Q24). When the power switch is
VCC
pushed, the CPU outputs the "PWR" control
signal to the power switching circuit to turn
the circuit ON.
Common 9 V converted from the HV line at
the +9 CTRL circuit (IC1330). The output
+9
voltage is applied to the 1st VCO (Q471),
etc.
Common 5 V converted from the +9V line at
the 5 V regulator circuit (IC1331). The out-
+5
put voltage is applied to the APC amplifier
(IC1251) and buffer amplifer (Q710), etc.
Common 5 V converted from the +9V line at
the 5 V regulator circuit (IC830). The output
DM+5
voltage is applied to the modulation ampli-
fi ers (IC831, IC832), etc.
Transmit 9 V controlled by the T+9 regula-
tor circuit (Q1333, Q1334, D1331) using the
T+9 "TXS" signal from the CPU (LOGIC-D unit;
IC50, pin 94). The output voltage is applied
to the APC amplifi er (IC1250), etc.
Transmit 5 V controlled by the T+5 regula-
tor circuit (Q1336, D1332, D1333) using the
T+5 "TXS" signal from the CPU (LOGIC-D unit;
IC50, pin 94). The output voltage is applied
to the RF amplifi er (IC1021), etc.
Receive 5 V controlled by the R+5 regulator
circuit (Q1337) using the "RXS" signal from
R+5 the CPU (LOGIC-D unit; IC50, pin 95). The
output voltage is applied to the RF amplifi er
(Q2) and 1st mixer (IC71), etc.
Transmit 3 V controlled by the T+3 regulator
circuit (Q1342) using the "TXS" signal from
T+3 the CPU (LOGIC-D unit; IC50, pin 94). The
output voltage is applied to the 1st mixer
(IC960), etc.
Receive 3 V controlled by the R+3 regulator
circuit (Q1343) using the "RXS" signal from
R+3 the CPU (LOGIC-D unit; IC50, pin 95). The
output voltage is applied to the RF amplifi er
(Q1), etc.
Description

4-5 PORT ALLOCATIONS

4-5-1 CPU (LOGIC-D UNIT; IC50)
Pin Port
number name
42 TXD1
43 RXD1
53 SDA
54 SCL
71 RESET
72 P2RSC
73 P2STC
74 PDATC
75 PSCKC
76 P1STC
77 +5AC
85 PCON
86 ULCK
94 TXS
95 RXS
D - 4 - 5
Description
Output data signals to the USB con-
troller (IC550, pin 24).
Input port for data signals from the
USB controller (IC550, pin 25) via the
(IC553).
I/O port for data signals from/to the
EEPROM (IC54, pin 5).
Outputs clock signal to the EEPROM
(IC54, pin 6).
Input port for reset signal form the re-
set IC (IC52, pin 1).
Outputs control signal to the mode
switch (MAIN-D unit; IC551, pin 5) via
the level converter (IC55).
Outputs strobe signal to the 2nd PLL
IC (MAIN-D unit; IC550, pin 3) via the
level converter (IC55).
Outputs the data signal to the 1st and
2nd PLL ICs (MAIN-D unit; IC400,
pin 15, IC550, pin 5) via the level con-
verter (IC55).
Outputs clock signal to the 1st and 2nd
PLL ICs (MAIN-D unit; IC400, pin 14,
IC550, pin 4) via the level converter
(IC55).
Outputs strobe signal to the 1st PLL
IC (MAIN-D unit; IC400, pin 16) via
the level converter (IC55).
Outputs control signal to the 5A
(Q1345) and D+5 (Q1347) regulators
via the level converter (IC55).
Low: While the +5 and D+5 regu-
lators are activated.
Outputs control signal to the TX power
controller (MAIN-D unit; Q1250).
Input port for the PLL unlock signal.
High: The PLL circuit is unlocked.
Outputs the T+5, T+3 regulator
circuits (MAIN-D unit; Q1336, Q1342)
control signal.
High: During transmit.
Outputs the R+5, R+3 regulator
circuits (MAIN-D unit; Q1337, Q1343)
control signal.
High: During receive.
