Icom ID-RP2 Service Manual page 67

Pin Port
number name
Outputs AFC switch (IC352, pin 5)
103 AFCSW
control signal.
Outputs clock signal to the D/A con-
105 DACK2
verter (IC57, pin 7).
Outputs the data signal to the D/A
106 DADAT2
converter (IC57, pin 6).
Outputs clock signal to the D/A con-
107 DACK1
verter (IC56, pin 7).
Outputs the data signal to the D/A
108 DADAT1
converter (IC56, pin 6).
Outputs strobe signal to the FPGA IC
128 FSTB
(IC200).
Outputs strobe signal to the liner
129 MSTRC C O D E C I C ( I C 1 ) a n d F P G A I C
(IC200).
Outputs the data signal to the liner
130 MDATC C O D E C I C ( I C 1 ) a n d F P G A I C
(IC200).
Outputs clock signal to the liner
131 MCLKC C O D E C I C ( I C 1 ) a n d F P G A I C
(IC200).
Outputs reset signal to the liner
132 MRESC C O D E C I C ( I C 1 ) a n d F P G A I C
(IC200).
Description
D - 4 - 6
