Icom ID-RP2 Service Manual page 15

[MAIN UNIT]
REF ORDER
NO. NO.
J5 6510011590 CNR B2P-VH
J6 6510003420 CNR B06B-EH-S
J8 6510003460 CNR B10B-EH-S
J10 6510022961 CNR 3012S-04R
J12 6510023331 CNR 3012S-02R
J13 6510023331 CNR 3012S-02R
J14 6510003390 CNR B03B-EH-S
J19 6450002100 CNR CMS1410-010010
J20 6450002100 CNR CMS1410-010010
J22 6510011590 CNR B2P-VH
J23 6510011430 CNR B3P-VH
J24 6510011590 CNR B2P-VH
J25 6510003440 CNR B08B-EH-S
J26 6510024420 S.CNR IC197-4807-2000
DS1 5040002420 S.LED SML-310MT T86
DS2 5040002420 S.LED SML-310MT T86
DS3 5040002420 S.LED SML-310MT T86
DS4 5040002420 S.LED SML-310MT T86
DS5 5040002420 S.LED SML-310MT T86
DS6 5040002420 S.LED SML-310MT T86
DS7 5040002420 S.LED SML-310MT T86
DS8 5040002420 S.LED SML-310MT T86
DS9 5040002420 S.LED SML-310MT T86
DS10 5040002420 S.LED SML-310MT T86
DS11 5040002420 S.LED SML-310MT T86
DS12 5040002420 S.LED SML-310MT T86
DS13 5040002420 S.LED SML-310MT T86
DS14 5040002420 S.LED SML-310MT T86
DS15 5040002420 S.LED SML-310MT T86
DS16 5040003070 LED MPG4371F
S2 2220000570 SW HSW1196-01-020
T1 5910000930 S.TSM H1081 <QUA>
[LED UNIT]
REF ORDER
NO. NO.
J1 6510003390 CNR B03B-EH-S
DS1 5040003070 LED MPG4371F
DS2 5040003070 LED MPG4371F
[CHASSIS UNIT]
REF ORDER
NO. NO.
W1 8900013310 CBL OPC-1324
W2 8900013300 CBL OPC-1325
W3 8900013290 CBL OPC-1326
W4 8900013280 CBL OPC-1327
W5 8900013270 CBL OPC-1328
W6 8900013260 CBL OPC-1329
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
DESCRIPTION M.
LOCATION
T 160.3/62.5
T 55/172.7
T 55/171
T 55/169.2
T 55/167.5
T 55/165.7
T 55/164
T 55/162.2
T 55/160.5
T 51.5/69
T 51.5/67
T 51.5/65
T 7.8/139.5
T 7.8/141.5
T 7.8/143.5
T 7.8/145.5
T 30/30.5
DESCRIPTION M.
LOCATION
DESCRIPTION M.
LOCATION
S.=Surface mount
H/V
H/V
H/V
B - 4 - 4
