Icom ID-RP2 Service Manual page 106

Pin Port
number name
Outputs the data signal to the D/A
108 DADAT1
converter (IC56, pin 6).
Outputs strobe signal to the FPGA IC
128 FSTB
(IC200).
Outputs strobe signal to the liner
129 MSTRC C O D E C I C ( I C 1 ) a n d F P G A I C
(IC200).
Outputs the data signal to the liner
130 MDATC C O D E C I C ( I C 1 ) a n d F P G A I C
(IC200).
Outputs clock signal to the liner
131 MCLKC C O D E C I C ( I C 1 ) a n d F P G A I C
(IC200).
Outputs reset signal to the liner
C O D E C I C ( I C 1 ) a n d F P G A I C
132 MRESC
(IC200).
Description
E - 4 - 6
