Icom ID-RP2 Service Manual page 44

[IF UNIT]
REF ORDER
NO. NO.
C65 4030011600 S.CER C1608 JB 1E 104K-T
C66 4030011600 S.CER C1608 JB 1E 104K-T
C67 4030011600 S.CER C1608 JB 1E 104K-T
C68 4030011600 S.CER C1608 JB 1E 104K-T
C69 4030011600 S.CER C1608 JB 1E 104K-T
C70 4030011600 S.CER C1608 JB 1E 104K-T
C71 4030011600 S.CER C1608 JB 1E 104K-T
C72 4030011600 S.CER C1608 JB 1E 104K-T
C73 4030011600 S.CER C1608 JB 1E 104K-T
C76 4030006860 S.CER C1608 JB 1H 102K-T
C80 4030011600 S.CER C1608 JB 1E 104K-T
C81 4030011600 S.CER C1608 JB 1E 104K-T
C82 4030011600 S.CER C1608 JB 1E 104K-T
C83 4030011600 S.CER C1608 JB 1E 104K-T
C120 4030011600 S.CER C1608 JB 1E 104K-T
C121 4030011600 S.CER C1608 JB 1E 104K-T
C122 4030011600 S.CER C1608 JB 1E 104K-T
C123 4030007010 S.CER C1608 CH 1H 100D-T
C125 4030006940 S.CER C1608 CH 1H 030C-T
C126 4030007050 S.CER C1608 CH 1H 220J-T
C128 4030006940 S.CER C1608 CH 1H 030C-T
C129 4030007070 S.CER C1608 CH 1H 330J-T
C131 4030011600 S.CER C1608 JB 1E 104K-T
C132 4030011600 S.CER C1608 JB 1E 104K-T
C133 4030011600 S.CER C1608 JB 1E 104K-T
C134 4030007070 S.CER C1608 CH 1H 330J-T
C135 4610001930 S.TRI TZC3P300A110R00
C136 4030006900 S.CER C1608 JB 1H 103K-T
C139 4030011600 S.CER C1608 JB 1E 104K-T
C140 4030011600 S.CER C1608 JB 1E 104K-T
C141 4030007010 S.CER C1608 CH 1H 100D-T
C142 4030007090 S.CER C1608 CH 1H 470J-T
C143 4030011600 S.CER C1608 JB 1E 104K-T
C144 4550006250 S.TAN TEESVA 1A 106M8R
C145 4030011600 S.CER C1608 JB 1E 104K-T
C146 4030011600 S.CER C1608 JB 1E 104K-T
C147 4030011600 S.CER C1608 JB 1E 104K-T
C148 4030007150 S.CER C1608 CH 1H 151J-T
C150 4030006860 S.CER C1608 JB 1H 102K-T
C199 4030007010 S.CER C1608 CH 1H 100D-T
C200 4030007130 S.CER C1608 CH 1H 101J-T
C201 4030009530 S.CER C1608 CH 1H 030B-T
C202 4030009530 S.CER C1608 CH 1H 030B-T
C203 4030007010 S.CER C1608 CH 1H 100D-T
C204 4030006850 S.CER C1608 JB 1H 471K-T
C205 4030011600 S.CER C1608 JB 1E 104K-T
C206 4550006390 S.TAN TEESVA 1C 335M8L
C207 4030006900 S.CER C1608 JB 1H 103K-T
C208 4030011600 S.CER C1608 JB 1E 104K-T
C209 4030007060 S.CER C1608 CH 1H 270J-T
C210 4030007030 S.CER C1608 CH 1H 150J-T
C211 4030007130 S.CER C1608 CH 1H 101J-T
C212 4030009500 S.CER C1608 CH 1H 0R5B-T
C213 4550006350 S.TAN TEESVB2 1A 226M8L
C214 4030006860 S.CER C1608 JB 1H 102K-T
C215 4030007010 S.CER C1608 CH 1H 100D-T
C216 4030011600 S.CER C1608 JB 1E 104K-T
C217 4030007050 S.CER C1608 CH 1H 220J-T
C218 4030009920 S.CER C1608 CH 1H 050B-T
C219 4030007130 S.CER C1608 CH 1H 101J-T
C220 4030007050 S.CER C1608 CH 1H 220J-T
C221 4030007130 S.CER C1608 CH 1H 101J-T
C222 4030011600 S.CER C1608 JB 1E 104K-T
C223 4030011600 S.CER C1608 JB 1E 104K-T
C225 4030011600 S.CER C1608 JB 1E 104K-T
C226 4030006860 S.CER C1608 JB 1H 102K-T
C227 4030017810 S.CER C1608 CH 1H 102J-T
C228 4030011600 S.CER C1608 JB 1E 104K-T
C229 4030009510 S.CER C1608 CH 1H 010B-T
C230 4030009510 S.CER C1608 CH 1H 010B-T
C231 4030007130 S.CER C1608 CH 1H 101J-T
C232 4030007130 S.CER C1608 CH 1H 101J-T
C233 4030006860 S.CER C1608 JB 1H 102K-T
C234 4030006860 S.CER C1608 JB 1H 102K-T
C235 4030011600 S.CER C1608 JB 1E 104K-T
C236 4030012660 S.CER C1608 JB 1E 683K-T
C237 4550006390 S.TAN TEESVA 1C 335M8L
C238 4030006860 S.CER C1608 JB 1H 102K-T
C239 4030011600 S.CER C1608 JB 1E 104K-T
C240 4030006860 S.CER C1608 JB 1H 102K-T
C241 4550006350 S.TAN TEESVB2 1A 226M8L
C242 4030006860 S.CER C1608 JB 1H 102K-T
C247 4030006900 S.CER C1608 JB 1H 103K-T
C248 4030006900 S.CER C1608 JB 1H 103K-T
C249 4030007170 S.CER C1608 CH 1H 221J-T
C250 4030007170 S.CER C1608 CH 1H 221J-T
C251 4030006900 S.CER C1608 JB 1H 103K-T
C252 4030009350 S.CER C1608 CH 1H 3R5B-T
C254 4030006900 S.CER C1608 JB 1H 103K-T
C255 4030006900 S.CER C1608 JB 1H 103K-T
DESCRIPTION M.
LOCATION
T 103.2/50.2
T 93.4/46.2
T 106.2/23
T 90.7/39
T 121/29
T 121/34
T 119.7/42.2
T 105.8/51
T 93/34
T 106.3/62.3
T 67.2/25.2
T 67.2/30
T 73.5/20
T 82.2/26
T 79.5/49.5
T 88.2/50
B 130/51.5
B 105.7/57.7
B 99.7/61.2
B 98.2/61.2
B 96.7/61.2
B 95.2/61.2
B 89.5/54
B 79.2/49.5
B 66.2/49.5
B 39.1/39.9
T 38.2/40.2
B 27.7/39.3
B 42.5/49.5
B 34/49.5
B 63.2/40.8
B 52/45.1
B 54.5/49.5
T 105.1/17.6
T 109.7/20.1
T 124.2/46.8
B 31.5/11.1
B 64.6/40.8
B 172.5/18.7
T 179.5/51.6
T 165.5/46.2
T 189.7/46
T 196/42.5
T 176/52.8
B 157.5/59.5
B 158.8/59.5
B 159.7/45.8
B 156.7/49.7
B 161.2/49.7
B 165.2/64.5
B 156.7/62.2
B 163.7/64.5
B 155.2/62.2
T 171.2/58.5
T 175/63.2
B 154.8/65
T 140.1/57
T 168.2/55.5
B 144.2/61.2
B 148.7/52
T 153/55.2
T 153/53.7
T 158.7/42
T 156.7/42
T 166.5/55.5
T 161.5/55.7
T 160.1/55.7
T 164.7/52.7
T 164.7/50
T 168.2/50
T 165.5/47.7
T 182.6/52.7
T 200.2/58.5
T 195.2/39.2
T 143.1/57
B 198.2/53.3
B 201.2/50.7
B 204.2/53.2
B 201.2/53.2
B 186.8/64.6
T 174.7/58.5
B 152/65
T 192.2/51.2
B 192.7/43.1
T 197.5/42.5
T 189.7/47.3
T 207.2/42.5
T 204.2/42.5
T 209.2/48
T 207.7/58.5
[IF UNIT]
REF ORDER
H/V
NO. NO.
C256 4030006900 S.CER C1608 JB 1H 103K-T
C257 4030006900 S.CER C1608 JB 1H 103K-T
C258 4030006900 S.CER C1608 JB 1H 103K-T
C259 4030007090 S.CER C1608 CH 1H 470J-T
C260 4030011600 S.CER C1608 JB 1E 104K-T
C261 4550006250 S.TAN TEESVA 1A 106M8R
C262 4030011600 S.CER C1608 JB 1E 104K-T
C263 4030006900 S.CER C1608 JB 1H 103K-T
C266 4030011600 S.CER C1608 JB 1E 104K-T
C267 4030011600 S.CER C1608 JB 1E 104K-T
C268 4510006450 S.TAN TEESVA2 0J 475M8R
C269 4030011600 S.CER C1608 JB 1E 104K-T
C270 4030011600 S.CER C1608 JB 1E 104K-T
C272 4030009520 S.CER C1608 CH 1H 020B-T
C273 4030011600 S.CER C1608 JB 1E 104K-T
C274 4030011600 S.CER C1608 JB 1E 104K-T
C275 4030007030 S.CER C1608 CH 1H 150J-T
C276 4030006850 S.CER C1608 JB 1H 471K-T
C277 4550006350 S.TAN TEESVB2 1A 226M8L
C278 4610001590 S.TRI TZC3R100A110R00
C279 4030009520 S.CER C1608 CH 1H 020B-T
C280 4030007010 S.CER C1608 CH 1H 100D-T
C281 4030007130 S.CER C1608 CH 1H 101J-T
C282 4030009520 S.CER C1608 CH 1H 020B-T
C283 4030007130 S.CER C1608 CH 1H 101J-T
C284 4030007010 S.CER C1608 CH 1H 100D-T
C285 4030007050 S.CER C1608 CH 1H 220J-T
C286 4610001590 S.TRI TZC3R100A110R00
C287 4030009510 S.CER C1608 CH 1H 010B-T
C288 4030006850 S.CER C1608 JB 1H 471K-T
C289 4030011600 S.CER C1608 JB 1E 104K-T
C290 4030006850 S.CER C1608 JB 1H 471K-T
C291 4030011770 S.CER C1608 CH 1H 060B-T
C292 4030011770 S.CER C1608 CH 1H 060B-T
C293 4030009500 S.CER C1608 CH 1H 0R5B-T
C294 4030007030 S.CER C1608 CH 1H 150J-T
C295 4030009510 S.CER C1608 CH 1H 010B-T
C296 4030009510 S.CER C1608 CH 1H 010B-T
C297 4030007040 S.CER C1608 CH 1H 180J-T
C298 4030007130 S.CER C1608 CH 1H 101J-T
C299 4030009520 S.CER C1608 CH 1H 020B-T
C300 4030009920 S.CER C1608 CH 1H 050B-T
C301 4030007120 S.CER C1608 CH 1H 820J-T
C302 4030007120 S.CER C1608 CH 1H 820J-T
C303 4030006860 S.CER C1608 JB 1H 102K-T
C304 4030007130 S.CER C1608 CH 1H 101J-T
C306 4030004760 S.CER C2012 JF 1H 104Z-T
C307 4030007130 S.CER C1608 CH 1H 101J-T
C308 4030007130 S.CER C1608 CH 1H 101J-T
C403 4030006850 S.CER C1608 JB 1H 471K-T
C404 4030006850 S.CER C1608 JB 1H 471K-T
C405 4030011600 S.CER C1608 JB 1E 104K-T
C406 4550006390 S.TAN TEESVA 1C 335M8L
C407 4030006900 S.CER C1608 JB 1H 103K-T
C408 4030011600 S.CER C1608 JB 1E 104K-T
C409 4030009920 S.CER C1608 CH 1H 050B-T
C410 4030011770 S.CER C1608 CH 1H 060B-T
C411 4030011770 S.CER C1608 CH 1H 060B-T
C412 4030009500 S.CER C1608 CH 1H 0R5B-T
C413 4550006350 S.TAN TEESVB2 1A 226M8L
C414 4030006860 S.CER C1608 JB 1H 102K-T
C415 4030007010 S.CER C1608 CH 1H 100D-T
C417 4030011600 S.CER C1608 JB 1E 104K-T
C418 4030007050 S.CER C1608 CH 1H 220J-T
C420 4030007130 S.CER C1608 CH 1H 101J-T
C421 4030007050 S.CER C1608 CH 1H 220J-T
C422 4030007130 S.CER C1608 CH 1H 101J-T
C423 4030011600 S.CER C1608 JB 1E 104K-T
C425 4030011600 S.CER C1608 JB 1E 104K-T
C426 4030011600 S.CER C1608 JB 1E 104K-T
C427 4030011600 S.CER C1608 JB 1E 104K-T
C428 4030006860 S.CER C1608 JB 1H 102K-T
C429 4030017810 S.CER C1608 CH 1H 102J-T
C430 4030007030 S.CER C1608 CH 1H 150J-T
C431 4030007030 S.CER C1608 CH 1H 150J-T
C432 4030006860 S.CER C1608 JB 1H 102K-T
C433 4030006860 S.CER C1608 JB 1H 102K-T
C434 4030011600 S.CER C1608 JB 1E 104K-T
C435 4030012660 S.CER C1608 JB 1E 683K-T
C436 4550006390 S.TAN TEESVA 1C 335M8L
C437 4030006860 S.CER C1608 JB 1H 102K-T
C438 4030011600 S.CER C1608 JB 1E 104K-T
C439 4030006860 S.CER C1608 JB 1H 102K-T
C440 4550006350 S.TAN TEESVB2 1A 226M8L
C441 4030006860 S.CER C1608 JB 1H 102K-T
C445 4030006900 S.CER C1608 JB 1H 103K-T
C447 4030006900 S.CER C1608 JB 1H 103K-T
C448 4030006960 S.CER C1608 CH 1H 050C-T
C449 4030006960 S.CER C1608 CH 1H 050C-T
C450 4030006900 S.CER C1608 JB 1H 103K-T
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
C - 5 - 4
DESCRIPTION M.
LOCATION
T 209.2/49.7
T 209.2/52.2
T 209.2/58.5
T 210.3/53.6
T 180.2/40.5
T 167/40
T 184/36.7
T 181.7/40.5
T 50.2/38.2
T 50.2/41.2
T 52.2/39.5
T 50.2/44.5
T 50.2/47.2
B 149.8/62.1
T 188.5/50.7
T 156.5/55.7
B 154.9/59.5
B 157.2/65.6
T 53/45.7
B 162.9/60.2
B 160.3/59.5
B 150/65
B 145.7/58.5
B 143.7/64.3
B 142.8/58.5
B 202.4/64.2
B 200.9/64.2
B 199.8/60.1
B 197.2/58.5
B 194.5/58.5
B 193.1/58.5
B 194.3/64.6
B 193.5/61.2
B 191/58.8
B 191.3/60.2
B 192.3/64.8
B 188.2/61.7
B 188.2/59
B 181.5/64.5
B 184.1/59
B 180/61.7
B 180/59
T 192.5/36.2
T 189.2/36.2
T 188.5/38.2
B 194/49.6
T 44.5/45.7
B 146.5/64.1
B 185/64.5
B 157.5/33
B 158/26.7
B 156.6/26.7
B 157.2/15.5
B 155.5/18.7
B 160/18.7
B 165.2/32.5
B 156.7/29.5
B 155.2/26.7
B 155.2/29.5
T 171/24.7
T 175.5/29.5
B 155.2/32.2
T 158/25.2
T 147.5/19
B 150.5/21.1
T 149/20.3
T 149/21.7
T 159.2/10.7
T 162.7/12.7
T 166.5/17.5
T 164.7/21
T 162/24
T 161/26
T 175.5/15.7
T 174.5/18.5
T 200/28.5
T 194.5/36.2
T 198/28.2
B 198.5/21.3
B 200.2/19
B 203.2/21.2
B 204.7/21.2
B 189/32.5
T 175.5/24.7
B 151/32.5
T 192/18.2
T 193.5/14.2
T 188.2/15
T 188.2/11.7
T 207.7/9.2
S.=Surface mount
H/V
