Icom ID-RP2 Service Manual page 76

[FRONT UNIT]
REF ORDER
NO. NO.
D1 1730002300 S.ZEN MA8082-M (TX)
D3 1790001711 S.DIO NNCD5.6C-T1-A
D4 1790001711 S.DIO NNCD5.6C-T1-A
D5 1790001711 S.DIO NNCD5.6C-T1-A
D6 1790001711 S.DIO NNCD5.6C-T1-A
S.RES ERJ12YJ271U (270 Ω)
R1 7030006250
S.RES ERJ12YJ331U (330 Ω)
R2 7030008180
R3 7030003860 S.RES ERJ3GE JPW V
R4 7030003860 S.RES ERJ3GE JPW V
R5 7030003860 S.RES ERJ3GE JPW V
R6 7030003860 S.RES ERJ3GE JPW V
C1 4030011600 S.CER C1608 JB 1E 104K-T
C2 4510008800 S.ELE EEE1EA100SR
C3 4030007050 S.CER C1608 CH 1H 220J-T
C4 4030007050 S.CER C1608 CH 1H 220J-T
C5 4030007050 S.CER C1608 CH 1H 220J-T
C6 4030007050 S.CER C1608 CH 1H 220J-T
C11 4030006850 S.CER C1608 JB 1H 471K-T
J1 6450002100 CNR CMS1410-010010
J3 6510020250 S.CNR B9B-PH-SM3-TB
DS1 5040003070 LED MPG4371F
S1 2220000630 SW MFS201N-16
[REAR UNIT]
REF ORDER
NO. NO.
D1 1790001711 S.DIO NNCD5.6C-T1-A
D2 1790001711 S.DIO NNCD5.6C-T1-A
D3 1790001711 S.DIO NNCD5.6C-T1-A
D4 1790001711 S.DIO NNCD5.6C-T1-A
D5 1790001711 S.DIO NNCD5.6C-T1-A
D6 1790001711 S.DIO NNCD5.6C-T1-A
D7 1790000700 DIO DSA3A1
D8 1790001711 S.DIO NNCD5.6C-T1-A
S.RES ERJ3GEYJ 680 V (68 Ω)
R1 7030003300
S.RES ERJ3GEYJ 680 V (68 Ω)
R2 7030003300
S.RES ERJ3GEYJ 680 V (68 Ω)
R3 7030003300
S.RES ERJ3GEYJ 101 V (100 Ω)
R4 7030003320
S.RES ERJ3GEYJ 101 V (100 Ω)
R5 7030003320
S.RES ERJ3GEYJ 680 V (68 Ω)
R6 7030003300
S.RES ERJ1TYJ 270U (27 Ω)
R7 7030011030
S.RES ERJ3GEYJ 151 V (150 Ω)
R8 7030003340
C7 4510008800 S.ELE EEE1EA100SR
J1 6510018920 S.CNR B8B-PH-SM3-TB
J2 6510016170 CNR 52018-8835
J4 6510011590 CNR B2P-VH
J5 6510011460 CNR B6P-VH
J6 6510018960 S.CNR B2B-PH-SM3-TB
DESCRIPTION M.
LOCATION
T 7.5/21.8
T 57.5/16.7
T 53/16.7
T 48.4/16.7
T 43.9/16.7
T 8.5/30.5
T 8.5/7.8
T 60.5/16.5
T 56/16.5
T 51.5/16.5
T 46.9/16.5
T 7.2/18.8
T 9.4/25.7
T 59/16.5
T 54.5/16.5
T 49.9/16.5
T 45.4/16.5
T 7.2/20.1
T 22.4/39.5
DESCRIPTION M.
LOCATION
T 36.9/71.8
T 32.9/71.8
T 24.9/71.8
T 20.9/71.8
T 16.9/71.7
T 12.9/71.8
T 28.9/71.8
T 36/76.4
T 32/76.4
T 24/76.4
T 20/76.4
T 16/76.4
T 12/76.4
T 35.3/21.3
T 28/76.4
T 40.8/26.6
[CHASSIS-D UNIT]
H/V REF ORDER
NO. NO.
IC1160 1150002020
J1 6510004910
MF1 2710000590
W1 8900010890
W2 8900010890
EP1160 6910000970
EP1161 6910000970
EP1162 6910000970
[CASE]
REF ORDER
NO. NO.
MF1 2710000750
W1 8900013140
W2 8900013210
W3 8900013240
W4 8900013170
EP1 6910008330
H/V
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
D - 5 - 9
DESCRIPTION
IC M57762-02
CNR NR-DS-E 01
FAN MF40D-12H-001
CBL OPC-1115
CBL OPC-1115
BEA DL-2OP 2.6-3-1.2H
BEA DL-2OP 2.6-3-1.2H
BEA DL-2OP 2.6-3-1.2H
DESCRIPTION
FAN FBA08A12LZ
CBL OPC-1323
CBL OPC-1307
CBL OPC-1373
CBL OPC-1306
E.OTH G80-18
H/V
M.
LOCATION
H/V
M.
LOCATION
S.=Surface mount
