Print Speed

The print speed is variable between 100 and 200 mm/sec. Generally, the
lower the speed, the better the printout quality. This is especially true
when printing bar codes with the bars running across the media path
("ladder style"), when printing on demanding face materials, and when
printing at low ambient temperatures. The default setting is 100 mm/sec.
(approx. 4 inches/sec.).
The combination of a large media roll (>152 mm/6 inches
diameter) and/or narrow media width in combination with
high print speed (>150 mm/6 inches per sec.) could cause
jerks in the media feed. Such jerks will compress text and
spoil the readability of ladder-style bar codes placed close
to the front edge of the label. In case of batch printing,
only the fi rst label in the batch will be affected. Negative
startadjust values tend to increase the jerks.
• If the media roll is larger than 152 mm (6 inches), do
not use a print speed >150 mm/sec.
• If a negative start adjust is used, do not use a print speed
>125 mm/sec.
• Narrow media width may require further restrictions on
print speed.
• Avoid placing text and ladder-style bar codes close to the
front edge of labels.
