Tear-Off with Quick-Load, cont.
1
Remove any empty core from the media
supply roll post.
3
If necessary, adjust the outer Quick-
Load guide to fi t the width of the media.
Intermec EasyCoder PF2i—User's Guide (Fingerprint version)
Chapter 4—Media Load
2
Fit a new roll of media on the supply
post and adjust the edge guide so
the roll becomes fl ush with the center
section.
4
Insert the media between the guides
and feed it forward until the media
reaches the platen roller and cannot be
inserted any further.
27
