Appendix B—Media Specifi cations

Self-Adhesive Labels

⇐ a ⇒ Media Width (including liner)
Maximum:
Minimum (standard):
Minimum (Quick-Load):
⇐ b ⇒ Liner
The backing paper must not extend more than a total of 1.6 mm (0.06
inches) outside the labels and should protrude equally on both side.
Recommended minimum transparency: 40% (DIN 53147).
⇐ c ⇒ Label Width (excluding liner)
Maximum:
Minimum:
⇐ d ⇒ Label Length
Maximum:
Minimum:
Under ideal circumstances, a minimum label length of 4 mm (0.16
inches) could be used. It requires the sum of the label length (d) and the
label gap (e) to be larger than 7 mm (0.28 inches), that batch printing is
used, and that no pull back of the media is performed. Intermec does not
guarantee that such short labels will work, but it is up to the user to test
this in his unique application.
⇐ e ⇒ Label Gap
Maximum:
Recommended:
Minimum:
The Label Stop Sensor must be able to detect the extreme front edges of
the labels. It can be moved between 5 fi xed positions (see Chapter 12).
Media Type Setup
• Label (w gaps)
116
60.0 mm (2.36 inches)
25.0 mm (1.00 inches)
40.0 mm (1.57 inches)
58.4 mm (2.30 inches)
23.8 mm (0.94 inches)
depends on SDRAM size
8.0 mm (0.32 inches)
21.3 mm (0.83 inches)
3.0 mm (0.12 inches)
1.2 mm (0.05 inches)
