• Roll Paper Length
Set the length of one page to print on roll paper.
When you place a checkmark on Auto Settings, the one-page length to be printed on roll paper is automatically set so
that the laid-out objects are printed on one page.
Note
• Available only if rolls are selected in Paper Source.
• You can input between 203.2 and 18000.0(mm) (between 8.00 and 708.66(inch)).
• You can change the numbers by clicking either ▲ button or ▼ button.
• Order
Set the object layout order.
The following settings are available for order.
Setting
Upper Left to Right
Upper Left to Bottom
Note
• When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Vertical, you
can choose only Upper Left to Right.
• When you have selected Roll Paper Length > Auto Settings and Paper Orientation > Horizontal,
you can choose only Upper Left to Bottom.
• Paper Size
You can select the size of the print media.
Note
• You cannot display this if Roll Paper is selected in Paper Source.

Zoom Dialog Box

This dialog box appears when you select Zoom from the View menu. You can enlarge or reduce the screen display.
• Scaling
Set the magnification for enlargement or reduction of the screen display.
Note
• You can input between 10 and 400.
• You can change the numbers by clicking ▼ button.
iPF8300S
The objects are laid out from upper left to right.
The objects are laid out from upper left to bottom.
