Problems with the printing quality
Printing is faint ............................................................................................................................................... 1071
Paper rubs against the printhead .................................................................................................................. 1072
The edges of the paper are dirty ................................................................................................................... 1073
The surface of the paper is dirty .................................................................................................................... 1074
The back side of the paper is dirty ................................................................................................................. 1074
Immediately after borderless printing, the trailing edge margin is soiled during regular printing ........................................... 1074
Printed colors are inaccurate ......................................................................................................................... 1075
Banding in different colors occurs ................................................................................................................. 1075
Colors in printed images are uneven ............................................................................................................. 1076
Image edges are blurred or white banding occurs ........................................................................................ 1077
Setting the Blue Switch on the Platen ....................................................................................................... 1078
The contrast becomes uneven during printing .............................................................................................. 1080
The length of printed images is inaccurate in the feeding direction ............................................................... 1080
Images are printed crooked ........................................................................................................................... 1081
Documents are printed in monochrome ........................................................................................................ 1081
Line thickness is not uniform ......................................................................................................................... 1081
Lines or colors are misaligned ....................................................................................................................... 1082
Problems with the printing quality caused by the type of paper .................................................................... 1082
Printing is faint
Cause
You may be printing on the wrong
side of the paper.
The Printhead nozzles are clogged.
Because the printer was left with-
out ink tanks installed for some
time, ink has become clogged in
the ink supply system.
Paper is jammed inside the Top
Cover.
The ink was not dry when paper
was cut.
Printing may be faint if Print
Quality in Advanced Settings in
the printer driver is set to Stand-
ard or Fast.
iPF8300S
Troubleshooting
Print on the printing surface.
Print a test pattern to check the nozzles and see if they are clogged.
(See "Checking for Nozzle Clogging.")
After the ink tanks have been installed for 24 hours, run Head Cleaning B from
the Control Panel.
(See "Cleaning the Printhead.")
Follow the steps below to remove the jammed piece of paper inside the Top Cov-
er.
1. Open the Top Cover and make sure the Carriage is not over the Platen.
2. Remove any scraps of paper inside the Top Cover.
(See "Clearing Jammed Roll Paper.")
(See "Clearing a Jammed Sheet.")
3. Close the Top Cover.
Specify a longer drying period in the Control Panel menu, in Paper Details >
Roll DryingTime.
(See "Menu Settings.")
→P.938
In Advanced Settings of the printer driver, choose Highest quality or High in
Print Quality.
Printing in Fast or Standard mode is faster and consumes less ink than in High-
est quality or High modes, but the printing quality is lower.
> Problems with the printing quality
Corrective Action
→P.1011
→P.1012
→P.1057
→P.1061
>
12
1071
Printing is faint
