4.
Press ▲ or ▼ to select TCP/IP, and then press the OK button.
5.
Press ▲ or ▼ to select IPv6, and then press the OK button.
6.
Press ▲ or ▼ to select IPv6 Support, and then press the OK button.
7.
Press ▲ or ▼ to select On, and then press the OK button.
Important
• Once you set IPv6 Support to On, the IPv6 StlessAddrs setting takes effect.
Note
• You can also configure IPv6 StlessAddrs and DHCPv6 from the printer Control Panel.
• The DNS can also be configured from the printer Control Panel.

Configuring the Printer Driver Destination (Windows)

This topic describes how to specify the printer driver destination if the printer's IP address is changed, or if you will use the
printer over a network connection instead of via USB connection.
The procedure described below is the configuration based on the LPR or Raw protocol using the standard TCP/IP port in
Windows ( Standard TCP/IP Port ).
Important
• If you will use the printer in a TCP/IP network, make sure the printer's IP address is configured correctly.
• Configuring the IP Address on the Printer
1.
Open the Printers and Faxes (or Printers, Devices and Printers ) window.
2.
Right-click the icon of this printer and choose Properties (For Windows 7 and Windows Vista, Printer Proper-
ties ) to open the printer properties window.
3.
Click the Port tab to display the Port sheet.
4.
Click Add Port to display the Printer Ports dialog box.
5.
In the Available Port list, select Standard TCP/IP Port.
6.
Click New Port.
After the wizard starts, a window is displayed for the Welcome to the Add Standard TCP/IP Printer Port Wiz-
ard.
7.
Click Next.
8.
In Printer Name or IP Address, enter the printer's IP address. If the DNS is configured, you can also enter the DNS
Domain Name.
