16 SymSafe/SymSafe Pro
User Manual

Monitor A/B composite output

When connecting directly from the SymSafe to the monitor, select the 75-Ohm impedance setting on the
monitor. If an additional device is connected to the monitor's looping output, set the termination of the
additional device as 75-Ohm, and set the termination of the monitor as Hi-Z (High Impedance).
Cable
Connectors

Alarm out connector

The 2 Alarm out connectors are provided for connections to audio/visual alarm notification devices such as
sirens and warning lights.
Table 9. Alarm out port pinouts
Alarm out number
Alarm out 1
Alarm out 2

Power Connector

Plug the power cord into the power cord connector and then into a properly rated wall socket. Once power is
applied to the unit, it will begin its power-up procedure. The unit will begin by displaying the software version
on Monitor-A, then the unit will begin recording automatically.
Table 10. Power supply rating
Voltage
Amps
75-Ohm
BNC
Pin
1
2
3
1
2
3
Power supply
100-240 VAC 50-60 Hz, auto-ranging
5
Description
NO (Normally open)
Common
NC (Normally closed)
NO (Normally open)
Common
NC (Normally closed)
