138 SymSafe
User Manual

Technical Specifications

General

Power Supply
AC Amps
Operating Temperature Range
Relative Humidity Range (Non-Condensing)
Dimensions
Weight

Connections

Accessory I/O Port
RS-232 Serial Port
Composite Video In
Composite Video Out
Audio In
Audio Out
10/100 Ethernet Port

Video

Video Signal Input
Video Signal Output
Input Termination
Colors
Gray Scale
Horizontal Resolution
Vertical Resolution
Video Compression Standard
Audio Compression Standard
100-240 Volt AC, Auto-Ranging
5A
Operating: 0 to 40 ºC. Storage: -20 to +60 ºC.
Operating: 10% to 80%. Storage: 10% to 95%
Inches: 3.5 x 15.5 x 16, mm: 89 x 394 x 406
19.4 - 20.5 lbs. (8.82 - 9.3 kg)
DB-9 Male. Accessories Port
RJ-45 Connector, 57600 Baud, 8,N,1, No flow control
BNC Connector
BNC Connector
RCA Connector
RCA Connector
RJ-45 Connector
0.7 to 1.4 Volts peak-to-peak, with Automatic Gain Control
1 Volt peak-to-peak into 75-ohm
75-ohm
Y:U:V 4:2:2, 16.8 Million Colors
256 Levels
720 Pixels
484 Lines
MPEG4
MPEG1 Layer 2
