GE Security SymSafe User Manual page 66

56 SymSafe/SymSafe Pro
User Manual
Figure 35. The Alarms/Alarms Inputs and Outputs menu after camera selection
Table 24. The Alarms/Alarms Inputs and Outputs menu options
Menu Option
Input Mode
Input type
Timeout
Macro
Protect
Buzzer
Email
Alarm Out 1
Alarm Out 2
PTZ Presets
Setting
• Latched: The alarm is activated until it is silenced and acknowledged.
• Transparent: The alarm is active only while receiving alarm input
• Timeout: The alarm condition is latched for the amount of time
specified in the Timeout field.
Normally Open, Normally Closed
0-59 minutes if Timeout selected in Input mode
None, Select Macro name (to select Macro Name you must have created
and named a macro in the Schedule/Macros menu
Enable or Disable
Enable or Disable
Enable or Disable
Enable or Disable
Enable or Disable
Enable, Address Presets, Presets 1-4 (launches the PTZ preset submenu
where you can assign an Enable flag, Bus address, PTZ address, and
Preset number.
