Seagate and Quantum SCSI Hard Drive Jumper Settings

The factory settings for the jumpers on the Seagate Barracuda SCSI hard drive
and the Quantum Viking SCSI hard drive are listed in the following table. The
settings are for a single drive installed in the system. The specifications for the
SCSI hard drives are included in Section 10.
Seagate and Quantum SCSI Hard Drive Jumper Settings
SCSI ID No.
0
1
2
3
4
5
6
7

Western Digital SCSI Hard Drive Jumper Settings

The factory settings for the jumpers on the Western Digital SCSI hard drive are
listed in the following table. The settings are for a single drive installed in the
system. The specifications for the SCSI hard drive are included in Section 10.
SCSI ID No.
0
1
2
3
4
5
6
7
Jumper Pins
No jumpers
A0 jumpered
A1 jumpered
A1 and A0 jumpered
A2 jumpered
A2 and A0 jumpered
A2 and A1 jumpered
A2, A1, and A0 jumpered
Western Digital SCSI Hard Drive Jumper Settings
Jumper Pins
No jumpers
1-2 jumpered
3-4 jumpered
1-2 and 3-4 jumpered
5-6 jumpered
1-2 and 5-6 jumpered
3-4 and 5-6 jumpered
1-2, 3-4, and 5-6 jumpered
SCSI ID No. Jumper Pins
8 A3 jumpered
9 A3 and A0 jumpered
10 A3 and A1 jumpered
11 A3, A1, and A0 jumpered
12 A3 and A2 jumpered
13 A3, A2, and A0 jumpered
14 A3, A2, and A1 jumpered
15 A3, A2, A1, and A0 jumpered
SCSI ID No. Jumper Pins
8 7-8 jumpered
9 1-2 and 7-8 jumpered
10 3-4 and 7-8 jumpered
11 1-2, 3-4, and 7-8 jumpered
12 5-6 and 7-8 jumpered
13 1-2, 5-6, and 7-8 jumpered
14 3-4, 5-6, and 7-8 jumpered
15 1-2, 3-4, 5-6, 7-8 jumpered
System Configuration 2-7
