5. SPI Protocol Definition

5.1. SPI Bus Protocol

While the SD Card channel is based on command and data bit-streams, which are initiated by a start bit and
terminated by a stop bit, the SPI channel is byte oriented. Every command or data block is built of eight bit bytes
and is byte aligned (multiples of eight clocks) to the CS signal.
Similar to the SD Bus protocol, the SPI messages are built from command, response and data-block tokens. All
communication between host and cards is controlled by the host (master). The host starts every bus transaction by
asserting the CS signal low.
The response behavior in SPI Bus mode differs from the SD Bus mode in the following three ways:
The selected card always responds to the command.
An eight or 16-bit response structure is used.
When the card encounters a data retrieval problem, it will respond with an error response (which
replaces the expected data block) rather than time-out as in the SD Bus mode.
In addition to the command response, every data block sent to the card during write operations will be responded
with a special data response token. A data block may be as big as one card write block (WRITE_BL_LEN) and as
1
small as a single byte.

5.1.1. Mode Selection

The SD Card wakes up in the SD Bus mode. It will enter SPI mode if the CS signal is asserted (negative) during the
reception of the reset command (CMD0). If the card recognizes that the SD Bus mode is required it will not respond
to the command and remain in the SD Bus mode. If SPI mode is required, the card will switch to SPI mode and
respond with the SPI mode R1 response.
The only way to return to the SD Bus mode is by power cycling the card. In SPI mode, the SD Card protocol state
machine is not observed. All the SD Card commands supported in SPI mode are always available.
The default command structure/protocol for SPI mode is that CRC checking is disabled. Since the card powers up in
SD Bus mode, CMD0 must be followed by a valid CRC byte (even though the command is sent using the SPI
structure). Once in SPI mode, CRCs are disabled by default.
CMD0 is a static command and always generates the same 7-bit CRC of 4Ah. Adding the "1," end bit (bit 0) to the
CRC creates a CRC byte of 95h. The following hexadecimal sequence can be used to send CMD0 in all situations
for SPI mode, since the CRC byte (although required) is ignored once in SPI mode. The entire CMD0 sequence
appears as 40 00 00 00 00 95 (hexadecimal).
1) The default block length is as specified in the CSD (512 bytes). A set block length of less than 512 bytes will
cause a write error. The only valid write set block length is 512 bytes. CMD16 is not mandatory if the default is
accepted.
SanDisk Secure Digital (SD) Card Product Manual, Rev. 1.9 © 2003 SANDISK CORPORATION 5-1
