2. Product Specifications

For all the following specifications, values are defined at ambient temperature and nominal supply voltage unless
otherwise stated.

2.1. System Environmental Specifications

Temperature
Humidity
ESD Protection

2.2. Reliability and Durability

Durability
Bending
Torque
Drop Test
UV Light Exposure
Visual Inspection/Shape and Form
Minimum Moving Force of WP Switch
WP Switch Cycles
SanDisk Secure Digital (SD) Card Product Manual, Rev. 1.9 © 2003 SANDISK CORPORATION
Table 2-1. System Environmental Specifications
Operating:
Non-Operating:
Operating:
Non-Operating:
Contact Pads:
Non Contact Pad Area:
Table 2-2. Reliability and Durability Specifications
10,000 mating cycles
10N
0.15N.m or ±2.5 deg.
1.5m free fall
UV: 254nm, 15Ws/cm
No warpage; no mold skin; complete form; no cavities; surface
smoothness ≤ -0.1 mm/cm
pollution (oil, dust, etc.)
40 gf (ensures that the WP switch will not slide while it is
inserted in the connector).
Minimum 1,000 Cycles @ slide force 0.4N to 5N
-25° C to 85° C
-40° C to 85° C
25% to 95%, non-condensing
25% to 95%, non-condensing
± 4kV, Human body model according to ANSI
EOS/ESD-S5.1-1998
± 8kV (coupling plane discharge)
± 15kV (air discharge)
Human body model per IEC61000-4-2
2 according to ISO 7816-1
2 within contour; no cracks; no
2-1
